Table 36 Rx Sensitivity - UMTS
HDPA+ / LTE LN930
Band Condition Min Rx Sensitivity Limit (dBm)
1 BER<0.1% -107
2 BER<0.1% -106
4 BER<0.1% -107
5 BER<0.1%
-107
8 BER<0.1% -107
LN930-AP (APAC SKU only)
Band Condition Min Rx Sensitivity Limit (dBm)
1 BER<0.1% -106
6 BER<0.1% -106
8 BER<0.1% -103
11 BER<0.1%
-106
19 BER<0.1% -106
GSM not supported for LN930-AP
Main and Diversity ports are measured separately. Combining both antenna ports
increases sensitivity by 3 dB. Table 36 Rx Sensitivity – UMTS reflects both ports
combined.
Table 37 Rx Sensitivity - LTE
HDPA+ / LTE LN930
EARFCN
LTE
Band
Duplex Modulation Bandwidth
(Hz)
Min Rx
Sensitivit
y Limit
(dBm)
Low
Channel
Middle
Channel
High Channel
1 FDD QPSK 10 -96 50 320 550
2 FDD QPSK 10 -95 650 920 1150
3 FDD QPSK 10 -97 1250 1678 1900
4 FDD QPSK 10 -96 2000 2110 2350
5 FDD QPSK 10 -97 2450 2510 2600
7 FDD QPSK 10 -96 2800 3100 3400
8 FDD QPSK 10 -97 3525 3625 3750
13 FDD QPSK 10 -97 5180 5230 5279
17 FDD QPSK 10 -97 5780 5800 5890
18 FDD QPSK 10 -97 5900 5925 5950
19 FDD QPSK 10 -97 6050 6075 6100
20 FDD QPSK 10 -94 6200 6300 6400
