User's Manual Part 2



  
UMTS FTP, Cat 14, QAM64
(M.2 DC-HSDPA+)
Band 1 771 mW
UMTS FTP, Cat 14, QAM64
(M.2 HSDPA+)
Band 1 813 mW
Standby Power
UMTS Stand-by current, DRX7, 16NB cells - 6 mW
UMTS Stand-by current, DRX7, 16NB cells (HN930) -
6.6 mW
Table 31
GSM Power Consumption
GSM Use Case Band Transmit Power
2UL, 1DL, PCL10 (*) GPRS 900 475 mW
2UL, 1DL, PCL5 (*) GPRS900 1482 mW
Standby Power
GSM Stand-by, DRX5, 16NB cells - 6 mW
GSM Stand-by, DRX5, 16NB cells (£) - 6.88 mW
(*) Applicable to modules: LN930, LN930-AP, HN930
(£) Applicable to module: HN930 (XMM™ 6260 based)
