User's Manual Part 2



  
 
This section lists the power consumption targets.
Typical target values at Vsys = 3.3 V
Table 29
LTE Power Consumption
M.2 Power Consumption (*) Transmit Power
LTE Use Case Band 10 dBm 23 dBm
LTE UTP, Cat. 3, 20 MHz, 100 RB - (APAC SKU only) 1 1195 mW 2195 mW
LTE UTP, Cat. 3, 20 MHz, 100 RB - (APAC SKU only) 3 1175 mW 2356 mW
LTE UTP, Cat. 3, 10 MHz, 50 RB - (APAC SKU only) 8 1000 mW 2201 mW
LTE UTP, Cat. 3, 20 MHz, 100 RB - (APAC SKU only) 9 1175 mW 2244 mW
LTE UTP, Cat. 3, 10 MHz, 50 RB - (APAC SKU only) 11 1073 mW 2155 mW
LTE UTP, Cat. 3, 15 MHz, 75 RB - (APAC SKU only) 18 1122 mW 1911 mW
LTE UTP, Cat. 3, 15 MHz, 75 RB - (APAC SKU only) 19 1112 mw 1874 mW
LTE UTP, Cat. 3, 15 MHz, 75 RB - (APAC SKU only) 21 1208 mW 2270 mW
LTE UTP, Cat. 3, 100 Mbps/50 Mbps, 20 MHz –
(APAC
not included)
7 1068 mW 2531 mW
LTE UTP, Cat. 3, max throughput, 10 MHz –
(APAC not
included)
17 916 mW 2394 mW
LTE Use Case Standby Power
LTE Stand-by current, DRX 1.28 s serv. Cell only 8 mW
(*) Applicable to modules:
LN930
LN930-AP
Table 30
UMTS Power Consumption
M.2 Power Consumption Transmit Power
UMTS Use Case
(DC-HSDAP+ or HSDPA+)
Band 10 dBm
UMTS FTP, Cat. 24, RxDiv
(M.2 DC-HSDPA+)
Band 1 988 mW
