ECS 400 i
Preface Copyright 2005 All Rights Reserved. The information in this document is subject to change without prior notice in order to improve reliability, design and function and does not represent a commitment on the part of the manufacturer. In no event will the manufacturer be liable for direct, indirect, special, incidental, or consequential damages arising out of the use or inability to use the product or documentation, even if advised of the possibility of such damages.
Notices Federal Communications Commission Radio Frequency Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
Table of Content BEFORE YOU START ........................................................................ 1 Federal Communication Commission Interference Statement................. 1 EUROPE – EU DECLARATION OF CONFORMITY ............................. 2 Let your computer acclimate itself............................................................. 9 Heat, Cold, Humidity, and Glare............................................................. 10 Suitable place to work..........................................
BATTERY CALIBRATION ................................................................30 RESETTING THE SYSTEM ..............................................................31 ADJUSTING THE B RIGHTNESS ........................................................31 USING THE W INDOWS ..................................................................31 Help Windows ........................................................................................... 31 Desktop...................................................
VGA UTILITIES ...........................................................................53 View............................................................................................................ 54 Hotkeys ...................................................................................................... 62 TROUBLESHOOTING ........................................................................65 LOCATING A PROBLEM .................................................................
Canadian DOC Notice For Class B Computing Devices This Class B digital apparatus meets all requirements of the Canadian Interference - Causing Equipment Regulations. Cet appareil numerique de la classe B repecte toutes les exigences du Règlement sur le matèriel brouilleur du Canada. Personal Inventory This Notebook computer system is designed for years of productive and pleasurable computing. Use this section to keep notes about details of your purchase. Update this section when you add new options.
Be fore you St a rt CONVENTIONS OF THIS M ANUAL Use this manual will help you get the most from your notebook computer. • If you are an experienced user of computers and/or Microsoft’s Windows operating systems, you might find it useful to read the Quick Start Guide that comes along with your accessories. • If you are a less experienced user, you should through the manual carefully before using your system.
fo llo wing me a sure s: • • • • Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to whic h the re c e ive r is c o nne c te d . Consult the dealer or an experienced radio/TV technician for help. This d e vic e c o mp lie s with Pa rt 15 o f the FC C Rule s.
• • Article 3.1(b): EN 301 489-1, 301 489-17 Article 3.2: EN 300 328 0976 C autio n: This e q uip me nt is inte nd e d to b e use d in a ll EU a nd EFTA c o untrie s. O utd o o r use ma y b e re stric te d to c e rta in fre q ue nc ie s a nd / o r ma y re q uire a lic e nse fo r o p e ra tio n. C o nta c t lo c a l Autho rity fo r p ro c e d ure to fo llo w.
2. 3. 4. 5. 6. 4 Please keep this User's Manual for later reference. Please disconnect this equipment from AC outlet before cleaning. Don't use liquid or sprayed detergent for cleaning. Use moisture sheet or cloth for cleaning. For pluggable equipment, that the socket-outlet shall be installed near the equipment and shall be easily accessible. Please keep this equipment from humidity. Lay this equipment on a reliable surface when installed. A drop or fall could cause injury.
7. 8. 9. 10. 11. 12. 13. 14. 15. 16. 17. Make sure to use the right voltage for the power source when connecting the equipment to the power outlet. Place the power cord in such a way that people can not step on it. Do not place anything on top of the power cord. All cautions and warnings on the equipment should be noted. If the equipment is not use for a long time, disconnect the equipment from the main power outlet to avoid being damaged by transient overvoltage.
18. 19. 20. 21. 22. 6 Ø The minimum specifications for the flexible cord are No. 18 AWG. B. For Japan: Ø All components of the cord set must bear a “PSE” or “ T ” mark and registration number in accordance with the Japanese Dentori Law. Ø The minimum specifications for the flexible cord are .75m ㎡ conductors. C. For Other Countries: Ø The cord set fittings must bear the certification mark of the agency responsible for evaluation in a specific country.
WICHTIGE SICHERHEITSHINWEISE 1. 2. 3. 4. 5. 6. 7. 8. 9. 10. 11. 12. 13. Bitte lesen Sie diese Hinweis sorgfältig durch. Heben Sie dirse Anleitung für den späteren Gebrauch auf. Vor jedem Reinigen ist das Gerät vom Stromnetz zu trennen. Versenden Sie Keine Flüssig- oder Aerosolreiniger. Am besten eignet sich ein angefeuchtetes Tuch zur Reinigung. Die Netzanschlußsteckdose soll nahe dem Gerät angebracht und leicht zugänglich sein. Das Gerät ist vor Feuchtigkeit zu schützen.
14. VORSICHT: Explosiongsgetahr bei unsachgemäßen Austausch der Batterie. Ersatz nur durch denselben oder einem vom Hersteller empfohlenem ähnlichen Typ. Entsorgung gebrauchter Batterien nach Angaben des Herstellers. 15. Dieses Schaltnetzteil kann bis zu einer Außentemperatur von maximal 35º C. 16. Die Ausgangswerte dürfen nicht die auf dem Label angegebenen Werte überschreiten. 17.
18. Bei der Benutzung Ihres Telefongerätes sollten Sie immer die grundlegenden Sicherheitsmaßnahmen beachten, um das Risiko von Feuer, Stromschlägen und Verletzungen zu minimieren. Zu beachten sind u.a. folgende Punkte: Ø Benutzen Sie das Gerät nicht in der Nähe von Wasser, wie zum Beispiel Badewanne, Waschbecken, Spülbecken, Waschbottich, in feuchten Kellerräumen oder in der Nähe von Schwimmbecken. Ø Benutzen Sie kein Telefon (ausgenommen schnurlose Modelle) während eines Gewitters.
After receiving your notebook when it’s hot or cold outside, try not to power up the computer immediately, let the computer adjust to the room temperature gradually at least for three to four hours. If your system arrives in cold weather, do not apply power to the computer or monitor until they have been allowed to come to room temperature. HEAT , COLD, HUMIDITY, AND GLARE Find a suitable place for your computer that’s not too hot, too cold, too dark, or too bright.
I nt roduc t ion WELCOME TO THE NOTEBOOK PC Congratulations on your purchase of the Notebook PC. Your Notebook features the latest advances in portable computing technology. The Notebook’ s modular design provides maximum expandability without compromising portability. GETTING TO KNOW Y OUR COMPUTER Opening the LCD Panel At the front of the Notebook you will find a retaining latch on the display panel that locks the display in closed position when the Notebook is not in use.
With the LCD screen open, you will see several features important for operating your Notebook computer. Each of these features is briefly described below. 1.
This computer provides a Light-to-voltage converter module which is a sensor directly proportional to the light intensity of your surrounding working environment. This will affect the backlight intensity (bright/dark) of your screen display. Ø Controlling the backlight intensity manually Use the hot-key combination of Fn+F7 and Fn+F8 respectively to decrease/increase the brightness of your LCD display.
Caps Lock Indicates when the keyboard is in Caps Lock mode. In this mode, the keyboard produces uppercase text when you press a key. When you press the Caps Lock key again, the indicator goes off and the keyboard produces lowercase text. Scroll Lock Indicates when the keyboard is in Scroll Lock mode. Some applications will move information across the screen differently when Scroll Lock is on. 5. 6.
1. 3. 4. 5. 6. BATTERY C HARGE This indicator will lit green when the battery is in charging status. When the indicator light turns off, it indicates the system is in full charge. AUDIO LINE O UT JACK MICROPHONE JACK IEEE 1394 PORT SPEAKERS 2. SUSPEND MODE This indicator will lit when the notebook enter the suspend mode. THE LEFT SIDE 1. THE MODEM PORT Always disconnect all telephone lines from the wall outlet before servicing or disassembling this equipment. To reduce the risk of fire use only No.
5. 6. 7. 8. VENTILATION OPENING USB PORT KENSINGTON L OCK ANTENNA PORT (OPTION FOR DVB-T USE) 9. PCMCIA SOCKET 10. PCMCIA RELEASE BUTTON 11. CARDR EADER Be sure the face of the card must be facing down when inserting it to the cardreader slot. THE RIGHT SIDE 1. 2.
When using a LAN, please use an EMI Shielding Cable to minimize an inteference when transmitting. 3. 4. EXTERNAL CRT PORT S-VIDEO TV O UTPUT THE REAR 1. 2. HINGE VENTILATION OPENING THE BOTTOM PANEL 1.
This model offers you with a “Free-Fall Detection” function and system alarm from excessive shock to decrease errors from process variaton and environmental stress. 2. 3. 4.
Ge t t ing St a rt e d CONNECTING TO A POWER SOURCE CONNECTING THE AC ADAPTER A universal AC adapter is provided to supply your computer with power and also charge the computer’ s battery pack. The adapter’ s AC input voltage can range anywhere from 100 to 240 volts, covering the standard voltages available in almost every country. The power cord for the AC adapter requires a three-hole grounded AC outlet. To connect the computer to an external power source: 1. 2.
Whenever possible, keep the AC adapter plugged into the Notebook and an electrical outlet to recharge the battery. Never turn off or reset your Notebook while the hard disk is in use and the CD-ROM status icon is lit; doing so can result in loss or destruction of your data. Always wait at least 5 seconds after turning off your Notebook before turning it back on; turning the power on and off in rapid succession can damage the Notebook’ s electrical circuitry.
Inserting and Removing the Battery Pack The battery pack should already be inserted in your Notebook computer when you unpack it. If not inserted, follow these directions: 1. 2. Turn over the notebook with the front of the unit facing you and place it on a solid, flat surface. Angle the battery into the bay. The front edge of the battery should slide into the grooves in the system case. Gently lower the battery into the bay and push it until it clicks securely in the bay. To remove the battery pack: 1.
Hold the battery at the finger grip and lift it out of the compartment. Charging the Battery Pack The installed battery pack charges automatically any time the computer is connected to the AC adapter and an external power source. It is a good idea to occasionally discharge the battery pack fully to preserve its operating performance. 3.
U sing t he N ot e book Com put e r ADJUSTING THE LCD SCREEN DISPLAY The LCD screen display can be adjusted by the following key combinations. KEYS [Fn] + [F7] [Fn] + [F8] [Fn] + [F10] [Fn] + [F12] FUNCTIONS Decreases the brightness level. Increases the brightness level. Use this key combination to expand your video screen or reset to its original size.
For information on connecting an external display, please refer to Chapter Four. A TOUR OF THE NOTEBOOK’S KEYBOARD The Notebook’ s keyboard uses a standard QWERTY layout with the addition of special function keys and an embedded numeric keypad for number intensive data entry. Your keyboard supports Windows by incorporating the two Windows specific keys. With the two Windows keys you will be able to access and take advantage of many of the timesaving features of Windows software.
Mail/MP3 Button Wireless Button [Fn] + [F2] [Fn] + [F3] [Fn] + [F4] [Fn] + [F5] [Fn] + [F7] [Fn] + [F8] [Fn] + [F9] [Fn] + [F10] [Fn] + [F12] Press this button to open Email/play MP3 files (option) Press this button to On/Off wireless function Turns on/off the volume. Decreases the speaker volume. Increases the speaker volume. Enable/Disable the system Touchpad function Decreases the brightness level. Increases the brightness level.
Do not rest heavy objects on the TouchPad or the TouchPad buttons. You can use the TouchPad with Microsoft Windows as well as nonWindows applications. • THE CD-ROM/DVD-ROM/COMBO FEATURES OF THE CD-ROM/DVD-ROM/COMBO MODULE The features of the CD-ROM/DVD-ROM/Combo drive are listed below. • The Audio Play feature allows you to play music CDs • Front panel load/unload button • Supports CD-DA, CD-ROM mode 1 and mode 2, MultiSession Photo CD™, CD-I/Video CD (pcs.) • Low power consumption • 12.
To remove a disk, do the following: 1. Check the LED display and make sure that the computer is not accessing the CD-ROM/DVD-ROM/Combo drive. 2. Push the eject button and pull the tray all the way out. 3. Carefully pick up the CD disk by the edges and – while pressing down on the center ring – remove the CD-ROM/DVDROM/Combo from the tray. Do not insert any foreign objects into the disc tray.
POWER S AVING MODES This section contains information on the Notebook’ s power system, including the AC Adapter, the battery system, recharging the battery, and tips for conserving battery power. The power system is comprised of two parts, the AC Adapter and the battery system. The AC Adapter converts AC power from a wall outlet to the DC power required by the computer.
To calibrate the battery pack follows the instructions below: 1. Insert the battery into the battery compartment and turn on the Notebook. If the battery is completely without power go to the next step. Otherwise, let the battery run down until the battery low-low warning beeps are heard. The system will automatically enter Suspend mode. 2. Turn the Notebook off. Connect the AC adapter and let the battery fully recharge. When the battery charge indicator turns off, the battery is fully charged. 3.
You will hear an audible beep signal every 5 seconds alerting you to the “ Battery Low” status. When the battery power reaches the “ Battery Low Low” status the beeping sound will accelerate. Your battery now has 1 ~ 2 minutes of battery charge remaining. You must save your data or connect AC power immediately; otherwise, you may lose your data. Sound Continuous beeping every 5 seconds Beeping accelerates Meaning Battery Low: Indicates that there is 7 to 10 minutes charge remaining.
2. 3. 4. 5. 6. Press the è arrow key until it reaches the “ Exit” menu screen. Again press the ê arrow key and select the “ Battery Calibration” item. Press the [Enter] key and disconnect the AC adapter then press the [Y] key until you hear continuous battery low-low warning beeping sounds. The system will be fully discharge and shutdown completely. Connect the AC adapter and let the battery fully recharge. The “ Battery Charge LED” of the notebook will light indicating it is in charging status.
DESKTOP Desktop may vary differently on the software installed in your notebook with different or additional shortcuts. Recycle Bin Used for storing deleted files in case you want to recover and save it in your system. The files will only be deleted from the Recycle Bin permanently only if you empty it by right clicking your mouse and select the “ Empty Recycle Bin” .
Start Button Allows easy access Windows programs. to all The Start menu allows you to adapt and show the programs used most frequently. If you wish to keep an item, right click the item and click Pin to Start menu. Log Off will enable the current user to log off and allows a new user to log on. Turn Off Computer allows you to shut down, restart, and Stand by modes for power saving purposes.
CONTROL P ANEL It is in this area that you can change how Windows looks and works. Click Start è Control Panel dialog box. There are two interfaces – Classic View or Category View.
De sk t op Ope ra t ion Your notebook is capable of providing you with efficient and productive mobile computing, it also has the speed and capacity to service as a desktop system. This chapter discusses those functions of your notebook that are typical of desktop systems. AUDIO THE MULTIMEDIA SOUND SYSTEM The Notebook’ s built-in audio capabilities allow you to take advantage of a wide range of education and entertainment multimedia software.
AUDIO V OLUME CONTROL The Notebook is equipped with hot-key volume controls: Pressing the [Fn]+[F3] hot-key combination decreases the audio output volume, press the [Fn]+[F4] hot-key combination increases the audio output volume. AUDIO SOFTWARE Your notebook comes equipped with an integrated sound system capable of providing you with quality audio sound through the builtin speakers or through external speakers connected via the system ports.
CONNECTING PERIPHERAL DEVICES To expand your computing capabilities, you can add a variety of external devices to your computer.
Page intentionally left blank 38
I nt e rne t Conne c t ion (Opt iona l) There are numerous ways to connect to the Internet. This may vary from the user’ s working environment as well as system specifications. • Using a modem and a telephone line • Using a wired LAN • Using a wireless LAN (Optional) USING A MODEM FOR CONNECTION TO INTERNET • • Use a telephone line to connect to the modem port of your computer. Do not use a digital telephone line.
40 3. In the “ Network Tasks” window, use your mouse pointer to click on the “ Local Area Connection” . 4. Select “ Properties” from the popup menu that appears 5. In the “ This connection uses the following items” field, select “ Internet Protocol (TCP/IP), and click “ Properties” .
6. Enter the system’ s IP and DNS server addresses on the General tab of the “ Internet Protocol (TCP/IP) Properties” window. If DHCP is used, click “ Obtain an IP address automatically” and “ Obtain DNS server address automatically” on the General tab.
7. After all the all the information are correctly entered in the “ Internet Protocol (TCP/IP) Properties” window, click “ OK” to finish. USING BOTH DHCP AND STATIC IP FOR CONNECTION TO INTERNET When you are alternatively using networks with either DHCP or static IP addressing, you can use alternative settings that enable simultaneous configurations of DHCP and static IP to use both of the network connects without reconfiguring. 1.
3. When you have completed the entire configuration, click “ OK” .
USING WIRELESS LAN NETWORK FOR CONNECTION TO INTERNET (MICROSOFT ’S SERVICE P ACK 2) (OPTIONAL ) 44
Running BI OS Se t up The BIOS (Basic Input and Output System) Setup program is a menu driven utility that enables you to make changes to the system configuration and tailor your system to reflect installed hardware or alter system performance. When the Notebook is turned back on, the system is configured with the values stored in CMOS.
Advanced - Use this menu to enable and make changes to the advanced features available on your system, such as enabling the FIR module. Security - Use this menu to set a password. The password allows bootup and controls access to the BIOS setup menu. Boot - Use this menu to configure the default system device used to locate and load the Operating System and for booting up the Notebook. Exit - Use this menu to exit the current menu or specify how to exit the Setup program.
Legend Key Alternate Key Function F9 Sets the parameters for the current menu to their default values. F10 Save and Exit. Enter Will select a sub menu or show a range of options for a field. L AUNCHING SUBMENUS Note that a right pointer symbol u appears to the left of certain fields. This pointer indicates that a submenu can be launched from this field. A submenu contains additional options for a field parameter.
THE M AIN MENU When the Setup program is accessed, the following screen appears: 48
THE ADVANCED MENU Selecting Advanced from the menu bar displays the Advanced menu: 49
THE SECURITY MENU The Notebook’ s advanced system of security allows you to set a password to prevent unauthorized access to system resources, data, and the BIOS Setup Program.
THE BOOT MENU The Boot menu allows the user to specify the order in which the Notebook is to check for a device to boot the system. You can also configure the way that the system will boot up. To make changes, select Boot from the menu bar.
THE EXIT MENU Once you have made all of your selections from the various menus in the Setup program, you should save your changes and exit Setup.
V GA U t ilit ie s VGA UTILITIES After you have restarted Windows, open the “ Control Panel” and double click on the “ Display” icon. From the “ Display Properties” window, select the “ Settings” tab and click on the “ Advanced” tab to enter the “ATI RADEON XPRESS 200M Series (Default LCD)" window.
V IEW 54
55
56
57
58
59
60
61
HOTKEYS 62
63
Page intentionally left blank 64
T rouble shoot ing This chapter describes locating and solving problems that you may encounter while using your computer. LOCATING A PROBLEM Problems with your computer can be caused by something as minor as an unplugged power cord – or as major as a damaged hard disk. The information in this chapter is designed to help you find and solve minor problems.
To check the power cables, and connections: 1. If you have been using battery power, connect the Notebook to an external power source and make sure that the battery has a charge. 2. If you are using the Notebook with the AC adapter, check the power outlet, the power cord, and any power switches that may affect your computer. 3. Check the wall outlet or power strip with an item that you know is functioning properly. A lamp or radio is a convenient item for checking the power.
Normally, the only test routine visible on the screen will be the memory test. Two classifications of malfunctions can be detected during the POST: • Error messages that indicate a failure with either the hardware, the software, or the Basic Input/Output System (BIOS). These critical malfunctions prevent the computer from operating at all or could cause incorrect and apparent results. An example of a critical error is microprocessor malfunction.
Solution: Correct the date and time using the DOS DATE and TIME commands or the options in the Setup Utility. If the date and time become incorrect after a short time, your CMOS battery may be depleted. Contact your dealer to change the battery. Problem: You hear irregular beeps during operation of the Notebook and the system halts. Solution: The problem is beyond the scope of this manual. Contact technical support. Problem: An unidentified message is displayed.
• • • What messages, if any, are on the screen? What software were you running at the time? What have you done already to try to solve the problem? If you have overlooked a step, your dealer may be able to solve the problem over the phone.
Page intentionally left blank 70
U pgra ding your Syst e m 71
UPGRADING YOUR SYSTEM CPU Refer to the following illustration on upgrading your notebook's CPU Be sure to loosen all the screws first before removing it totally to release the heatsink. Failure to do so will cause a major damage to the heatsink.
UPGRADING YOUR MEMORY THE E ASY TO UPGRADE HDD MODULE The hard drive in your notebook computer is made to be easily swapped out for upgrading.
Page intentionally left blank 74
Spe c ific a t ion DETAILED NOTEBOOK SPECIFICATIONS Processor Intel® Pentium® M processor, (2MB/1MB L2 cache, 533/400 MHz FSB) • Intel® Celeron® M processor, (1MB/512KB L2 cache, 400 MHz FSB) • 478pin mFCPGA package Operating System Compliance • Microsoft® Windows® XP Professional Edition • Microsoft® Windows® XP Home Edition Core Logic • ATI® RC410MB + SB450 Memory • Expansion 2 slots of 200pin SO-DIMM DDR2 module, expandable up to 2GB system memory • Support DDR2 400/533 module LCD Display • 14.
Optical Drive • 12.7 mm height Combo Drive (DVD-ROM + CD-RW), DVD Dual (DVD+/-RW), Super Multi (DVD-RAM+DVD+/-RW) Pointing Device • Touchpad Application Launch Key • WLAN on/off, Picture, MP3 LED Status Indicator • Suspend/Resume, Battery Charging Status, Hard Disk Access, NumLock mode, CapsLock mode, ScrollLock mode Keyboard • 3.0mm travel, Inverted-T, 88 keys with Windows keys PCMCIA • One Type II PCMCIA slot, support CardBus Camera (option) • CMOS Camera, 1.
802.11 b/g network connection (AzureWave /AW-GM100) Power Management • PC 2001 and ACPI compliance • Support Stand-by, Suspend to Disk, Suspend to RAM, Smart Battery System support Security • Kensington Lock Size • 329 x 273 x 26.3 (mm) Weight • Approximately 2.3 kg with panel, battery and Optical drive installed Packing Accessories • Quick Guide, Support CD (Driver, Utility, Manual), AC Adapter, Power Cord, Battery Pack Factory Option • QCOM WLAN Q802MKG(3A1) Ralink 802.
