Kestrel Series Kestrel Tension Series Electric Floor Rising Projection Screen USER’S GUIDE Rev. 062310-JA www.elitescreens.com info@elitescreens.
Kestrel Accessories Kestrel Qty 1 Radio Frequency Remote Control Qty 1 5-12V Trigger Qty 2 AAA batteries Qty 1 Infrared Remote Control Qty 1 IR “eye” Receiver Qty 1 Low Voltage 3-way Wall Switch IMPORTANT SAFETY NOTES 1. Please rea d this m a nual b efo r e us e and follo w th e pr oc edu res s p ec if ied : a. Please retain this manual for future reference. b. To avoid any damages to the screen, do not use any accessories or parts not recommended by Elite Screens. c.
NOTE: This equipment has been tested and found to comply with the limit s for a Class B digital device pursuant to Part 15 of the FCC Guidelines. The products are designed t o provide reasonable protection against harmful interference in a residential/commercial installation and end user application and may radiate radio frequency energy. However, there is no guarantee that interference will not occur in a particular installation.
IR receiver window Controlling the Kestrel Series with the 5-12V trigger, Extended IR “eye” receiver or 3-way wall box switch: 1. 5-12V Trigger: Connect the 5-12 volt trigger cable to your projector’s trigger output via a separate cable that may or may not be provided by the projector manufacture. The trigger feature will not work without an output cable from the projector, but it can be tested using a 9-volt battery by simply connecting the Red (+) and Green (-) cable to the 9-volt battery 2.
Kestrel Series Dimensions Table Unit: mm 1463.0 L/R Black Masking Border (A4) 50 Top Black Masking Border (B3) 76 1706.9 50 76 1970.4 1869.4 50 2223.0 2133.0 2032.0 1798.0 1766.0 1695.0 2064.0 2032.0 1960.6 92" (16:9) 2232.0 2200.0 FE100H 100" (16:9) 2420.0 FE85C 85" (2.
Kestrel Tension Series Dimensions Table Unit: mm Model Diagonal Size/Aspect Ratio Case Length (A) Top panel Length (A1) Screen Width (A2) View Width (A3) L/R Black Masking Border (A4) Top black drop (B3) Screen Material to Bottom Bar (B1) View Height (B2) Screen Overall Height (B) Bottom black drop (B4) N.W. (KGS) FTE84V 84" (4:3) 2021.0 1989.0 1858.9 1706.9 76 76 2134.2 1280.2 2244.2 762.0 22.3 FTE92V 92" (4:3) 2174.0 2142.0 2021.4 1869.4 76 76 2103.7 1402.1 2213.
Warranty Policy Two (2) year parts and labor warranty from defects in workmanship from purchase date as follows Each party will be responsible for one way shipping during the warranty period. Elite Screens is not responsible for applicable International tariffs such as broker fees and custom duties. A RMA (Return Merchandise Authorization) number must be issued in order to process a replacement or to authorize a return for warranty repair.
CONTACTS US & Canada Tech Support & Warranty Claim Please contact us at service@elitescreens.com or call +1 877-511-1211 #3 Service Europe Tech Support & Warranty Claim Please contact us at service@elitescreens.eu or call +49-(0) 40-30392958 Asia Tech Support & Warranty Claim Please contact us at service@elitescreens.com.cn or call +86-(0) 755-8461-7989 Taiwan Tech Support & Warranty Claim Please contact us at service@elitescreens.com.
