USER MANUAL 3‐Axis Indoor Mini IR Dome ELI‐EDC eLineTechnology.
CAMERA ELI‐EDC USER MANUAL eLineTechnology.com Table of Contents PRODUCT DESCRIPTION ....................................................................................................................... 3 FEATURES ............................................................................................................................................... 3 MODELS..............................................................................................................................................
CAMERA ELI‐EDC USER MANUAL eLineTechnology.com Product Description 3‐Axis Indoor Mini IR Dome Congratulations on your purchase of this product. This analog surveillance dome features advanced functions in a compact body and is suited for tight, indoor environments such as a corridor or elevator. The camera utilizes advanced Sony image sensor technology producing high definition, realistic color.
CAMERA ELI‐EDC USER MANUAL eLineTechnology.com CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. FCC Statement THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: 1. 2. THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.
CAMERA ELI‐EDC USER MANUAL eLineTechnology.com Product Diagrams Plastic Housing Infrared LEDs Lens Plastic Dome Installation Mounting This is an indoor camera. It is not suitable for exposure to particles or liquids. 1. Unscrew the mounting base from the camera by twisting counter‐clockwise. Use this base as a guide to mark the locations for screw and cable management holes on the mounting surface. Make note of the arrow on the base indicating the front of the camera.
CAMERA ELI‐EDC USER MANUAL eLineTechnology.com Caution: Once power is supplied, do not remove the camera from the mounting base due to risk of electrical shock. Connections 1. Use a BNC connector to connect the camera’s VIDEO OUT to the monitor’s (or DVRs) VIDEO IN. Use the following recommendations for cable types and distances: Maximum Cable Length Type of Coaxial Cable Recommended Max Cable Length RG‐59/U 250 M 825 ft RG‐6/U 500 M 1650 ft RG‐11/U 600 M 1980 ft RG‐15/U 800 M 2640 ft 2.
CAMERA ELI‐EDC USER MANUAL eLineTechnology.com Adjusting the Camera 1. To adjust the camera angle, remove the white casing and dome by pressing on the latch release indicated by the arrow, and prying off the casing. The first time you remove the casing, it may be a little tight. 2. The camera lens can be moved by twisting the black shell inside the white base. The camera module inside the black shell can be moved up and down. There is no need to remove any screws or to attempt to disassemble the camera.
CAMERA ELI‐EDC USER MANUAL eLineTechnology.com On‐Screen Display (OSD) Settings On the OSD control device on the cable, hit the center button to activate the OSD settings. The menu as below will appear. Use the button by moving up/down/left/right and depressing as ‘Enter’ to change OSD settings. For further definition of each setting see the eLine web site under Support. http://www.elinetechnology.com.
CAMERA ELI‐EDC USER MANUAL eLineTechnology.com Specifications Feature Specification Minimum Illumination S/N Ratio Scanning System Synchronous System Auto Electronic Shutter Gamma Characteristic IR Distance Video Output Auto Gain Control Power/Current Dimension Weight Storage Temperature Operating Temperature 0.001 Lux / 0 Lux (with IR LED ON) More than 50dB 2:1 Interface Internal, Negative sync NTSC: 1/60s~1/100,000s / PAL: 1/50s~1/100,000s 0.45 20 Meters (with ȼ5x21 pcs Infrared LED) 1Vpp.
CAMERA ELI‐EDC USER MANUAL eLineTechnology.com Warranty Repair/Replacements Subject to the terms of the limited warranty in effect at the time of purchase, e‐Line will repair or replace a product that fails to meet the terms provided, within the product’s warranty period. eLine reserves the right to replace any product under warranty with new, refurbished or remanufactured product.
