Product Specifications
FEATURES Golden 24
Elica Design Center
CALABRIA
Accessories
Line Drawing
FEATURES
Size (in) & Type 30”, 36”, 42” or 48” Wide Wall-Mount
Finish
Controls
Illumination
Installation Type
Blower Type
Filter Type
Noise (sones) *Working speed:
Duct Transition
Stainless steel
In/Out Backlit Knob
2 LED (30", 36" & 42" Units) 7.5 watts LED light, replaceable lamps (1 intensity)
4 LED (48" Unit) 7.5 watts LED light, replaceable lamps (1 intensity)
Ducted Installation Only
30" Min: 3.21, Max: 7.7 Sones
36", 42", 48" Min: 3.21, Max: 7.7 Sones
600 CFM, 4-Speed Internal (30” Unit)
1200 CFM, 4-Speed Internal (36”, 42”, 48” Units)
Blower Performance Speed 1 (For 30”) 205 CFM, (For 36”, 42" & 48“) 375 CFM
Speed 2 (For 30”) 350 CFM, (For 36”, 42" & 48“) 640 CFM
Speed 3 (For 30”) 510 CFM, (For 36”, 42" & 48“) 940 CFM
Speed 4 (For 30”) 600 CFM, (For 36”, 42" & 48“) 1200 CFM
Dishwasher-Safe, Professional Stainless Steel,
Angled Bae Filters 2(30" & 36" Units) 3(42" & 48" Units)
10” Round with Back Draft Damper (top and rear)
Electrical 120V-60Hz
Consumable parts
Consumable pa rts are sold in units of one (1). O rder acco rdingl y.
Replacement Grease Filter (1)
CODE: GF09EA (30”)
CODE: GF09FA (36” & 42”)
CODE: GF09GA (48”)
Replacement Light Bulb (1)
CODE: 2006BH
HEAT
GUARD
PR OF E SSIONA L
PE RFO R M A N C E
PLUS
HUSH SYSTEM
An exclusive sound deadening technology that effectively reduces sound levels by
over 35%, compared to typical range hoods.
LED LIGHT
LED lighting is undoubtedly the smartest solution in terms of energy saving. Expected
life time of over 20.000 hours, represents the most remarkable advantage of LED
light bulbs.
PROFESSIONAL PERFORMANCE
Special features and very high performances for models with aspiration capacity
between 600 and 1200 CFM’s, and noise level between 65 and 75 db(A) at maximum
speed. The ideal complement of PRO ranges.
HEAT GUARD
A safety feature that protects the hood and cabinetry from excessive heat, by sensing
extreme temperatures (>158 degrees) and will automatically adjusts the blower speed
to HIGH. Blower speed will automatically adjust back once temperatures drop to a
safe level.
KIT # Part
30”
(76 cm)
36”
(91.54 cm)
42”
(106.5 cm)
48”
(121.7 cm)
Long Chimney
Extension
Kit 6”
KIT02159 KIT02158 KIT02622 KIT02164
Long Chimney
Extension
Kit 12”
KIT02160 KIT02161 KIT02623 KIT02165
Heat Lamp
w/ 2 - 175W
Bulbs Kit
KIT0142857 KIT0142858 KIT0142861 KIT0142863
Stainless Back
Splash and Warm
Racks Kit
KIT0142864 KIT0142867 KIT0142868 KIT0142870
Models
ECL630S3 ECL136S3 ECL142S3 ECL148S3
A 30”(76 cm) 36”(91.1 cm) 42”(106.5 cm) 48”(121.7 cm)
B 25” (63.5 cm)
C 18” (45.7 cm)
D 12” (30.3 cm)
E 1
5
⁄8” (5.7 cm)
F 29
1
⁄8” (74 cm) 35
1
⁄8” (89.2 cm) 41
1
⁄8” (104.5 cm) 47
1
⁄8” (119.7 cm)
G 7
1
⁄2” (19 cm)
H 2
9
⁄16” (6.5 cm)
I
3
⁄8” (1 cm)
H
I
E
F
A
B
D
C
G
