PARTS IDENTIFICATION
Switch 12 Position
9mm Nut
Alligator Clip Switch PC Mount
Capacitor
Washer
PC Board
IDENTIFYING CAPACITOR VALUES
Capacitors will be identified by their capacitance value in pF (picofarads), nF (nanofarads), or μF (microfarads). Most
capacitors will have their actual value printed on them. Some capacitors may have their value printed in the following
manner. The maximum operating voltage may also be printed on the capacitor.
Second Digit
First Digit
Multiplier
Tolerance
The letter M indicates a
tolerance of +
20%
The letter K indicates a
tolerance of +
10%
The letter J indicates a
tolerance of +5%
For the No.01234589
Multiply By 1 10 100 1k 10k 100k .01 0.1
Multiplier
Note: The letter “R” may
be used at times to
signify a decimal point;
as in 3R3 = 3.3
103K
100V
Maximum
Working Voltage
The value is 10 x 1,000 = 10,000pF or .01μF 100V
10μF 16V
METRIC UNITS AND CONVERSIONS
Abbreviation Means Multiply Unit By Or
p Pico .000000000001 10
-12
n nano .000000001 10
-9
μ micro .000001 10
-6
m milli .001 10
-3
– unit 1 10
0
k kilo 1,000 10
3
M mega 1,000,000 10
6
1. 1,000 pico units = 1 nano unit
2. 1,000 nano units = 1 micro unit
3. 1,000 micro units= 1 milli unit
4. 1,000 milli units = 1 unit
5. 1,000 units = 1 kilo unit
6. 1,000 kilo units = 1 mega unit
Electrolytic capacitors have a positive
and a negative electrode. The negative
lead is indicated on the packaging by a
stripe with minus signs and possibly
arrowheads.
Warning:
If the capacitor is
connected with
incorrect polarity, it
may heat up and
either leak, or
cause the capacitor
to explode.
Polarity
Marking
