Use and Care Manual

8
WWW.VINOTEMP.COM
PARTS AND SPECIFICATIONS
Model No.
Voltage
AC 115V
Frequency
60 Hz
Ambient Temperature Range
60.8°- 89.6°F
Control Temperature Range
36°- 68°F
Refrigerant
R600a/24g
Power Consumption
0.88 kWh/24h
Input Power
75W
Volume
4.45 in cu/ft
Net Weight
71.65 lbs
Gross Weight
84.22 lbs
Dimensions (W x D x H)
19.87 in x 21.5 in x 31.5 in
Box Dimensions (W x D x H)
25.59 in x 28.35 in x 35.63 in
*Note: EL-BCU101-01
Storing large and/or oddly shaped
EL-BCU101-01
1
2
1
2
Shelves
storage capacity is based on a standard 330ml cans.
cans will decrease the capacity of the beverage cooler.
