Appendix D: MIDI D-3
NOISE CC
Parameter Encoder CC MSB CC LSB Data Range MSB Data Range LSB
Noise S&H A 75 - 0-127 -
B - - 0-127 -
Noise Fade C 76 - 0-127 -
D - - 0-127 -
Noise Level E 77 - 0-127 -
F - - 0-127 -
G - - 0-127 -
H - - 0-127 -
I - - 0-127 -
J - - 0-127 -
OSC 2 NRPN
Parameter Encoder NRPN MSB NRPN LSB Data Range MSB Data Range LSB
Pitch A 1 20 0-127 0-127
B 1 0-127 -
Detune C 1 22 0-127 -
Keytracking D 1 23 0-127 -
Level E 1 24 0-127 -
Waveform F 1 25 0-127 -
Sub Oscillator G 1 26 0-127 -
Pulsewidth H 1 27 0-127 -
PWM Speed I 1 0-127 -
PWM Depth J 1 29 0-127 -
OSC 2 CC
Parameter Encoder CC MSB CC LSB Data Range MSB Data Range LSB
Pitch A 17 49 0-127 0-127
B - - 0-127 -
Detune C - - 0-127 -
Keytracking D - - 0-127 -
Level E 78 - 0-127 -
Waveform F 79 - 0-127 -
Sub Oscillator G 80 - 0-127 -
Pulsewidth H 81 - 0-127 -
PWM Speed I 82 - 0-127 -
PWM Depth J 83 - 0-127 -
