Instruction Manual [For iPod, iPhone and iPad User]
Main Unit Location of Control FCC ID: PEQA480110813 Electronics Tomorrow Ltd. Model No: A480 DC 4.5V 3 X 1.5V - - MADE IN CHINA 1. Snooze button / LED indicator 2. 3. 4. 5. Pair Reset Alarm Battery Compartment 6.
Features Thank you for purchasing the Vibration Alarm. This product is designed as a Vibration Alarm by working with your iPad, iPhone, iPod or other iOS devices. - Support iOS version 7 or above; - Support Bluetooth version 4.0. - Set wake up buzzer alarm or vibration alarm with snooze function, up to 10 alarms. - Take full control of the Vibration Alarm with i-device app via Bluetooth Low Energy. - Selectable alarm tone pattern and volume to different alarms. - Set count down timer.
Getting started 1. Install battery: 1.1 Open the battery compartment. 1.2 Insert 3 x AAA batteries in polarity (+) and (-) as indicated. 1.3 Close the battery compartment. FCC ID: PEQA480110813 Electronics Tomorrow Ltd. Model No: A480 DC 4.5V 3 X 1.5V - - MADE IN CHINA 2. Install BleAlarm App on your mobile device. 2.1 Access app store and search for BleAlarm 2.2 Select and install BleAlarm App on your mobile device. BLE ALARM .
Pairing the Vibration Alarm 3. Pair the Vibration Alarm with BleAlarm app. 3.1 Before running the BleAlarm app, make sure the Bluetooth is turned ON at your i-device. 3.2 After you tap the app icon , the ‘Nearby Devices’ screen appears. You need to pair the Vibration Alarm device before you enter the main app screen.
Pairing the Vibration Alarm 3.5 The New Vibration Alarm will be displayed on App and is ready for pairing. Tap the "New Vibration Alarm" will start the pairing 3.4 Press and hold the [PAIR] and connection process. button on the Vibration Once the Vibration Alarm Alarm device for 5 is paired, it will start time seconds. You can find and data synchronization. the flashing LED will turn from red to blue. 3.3 Tap “ Pair New Device” to search for nearby devices.
Pairing the Vibration Alarm 3.6 Once connected, the following information will be synchronized: i) Current time and date ii) Alarms & timer setting iii) Unit battery level 3.7 One Vibration Alarm unit can pair one idevice each time. 3.8 One idevice can pair up to 5 Vibration Alarm units.
Rename the Vibration Alarm 4. Rename the device. Tap the device name (default is “Vibration Alarm”) at the top of the screen to edit the Vibration Alarm device name.
Battery status indicator 5. Battery status indicator It indicates the battery level of your Vibration Alarm device.While the battery level drops below 20%, the battery icon is in red status and a low battery warning will pop up to remind battery replacement.
Setting the alarm time 6. Setting the alarm time 6.1 Tap [New Alarm] to create a new alarm or tap the existing alarm to modify. 6.2 On alarm setting screen, you can edit and adjust the item below: i) Alarm Name: Tap to edit you preferred name to this alarm. ii) Time: Scroll up and down to adjust the alarm time. iii) Day of Week: Tap to select which day of week to enable the alarm. - If none is selected, it alarms once only. - If all days are selected, it alarms daily.
Setting the alarm time v) Alarm volume level: Tap to select the alarm sound volume level (three options: Low, Med and High). vi) Vibration strength: Tap to select the vibration strength (four options: Off, Low, Med and High). 6.3 Complete the alarm setting. i) Tap [Done] to save the alarm setting and go back to main screen. ii) Tap [Cancel] to restore to the original alarm setting and go back to main screen. iii) Tap [Delete Alarm] to delete the current alarm and go back to main screen.
Snooze operation 7. Using the SNOOZE function 7.1 When the alarm sounds, press [Snooze] and alarm will repeat every 5 minutes up to three times. 7.2 Above default value can be adjusted by setting the “Maximum Snoozes” and “Snooze Duration” in the preference screen.
To turn off the alarm 8. To disable the alarm 8.1 When alarm sounds, press [Snooze] once to stop the alarm and activate the snooze funtion, or press [Alarm] to disable the alarm completely. 8.2 If no button is pressed, The alarm will sound for 1 minute and stop automatically. If Snooze Enabled setting is ON, the alarm will repeat every 5 minutes. You can press the [Snooze] button to stop the alarm, or can press [Alarm] button to turn off the alarm and 8.
Setting the Timer 9. To set the timer Tap timer on main screen to go into setting screen. 9.1 You can edit and adjust items below on this screen. i) Timer period: Scroll up and down to adjust the timer duration. Sound pattern: Tap to select the tone pattern (5 options plus one random pattern available). iii) Sound volume level: Tap to select the sound volume level (Four options: Off, Low, Med and High). iv) Vibration: Tap to select the vibration strength (Four options: Off, Low, Med and High).
Setting the timer 9.2 Using the Timer In the Home screen, tap “Start” under Timer to start counting. Tap “Stop” to stop counting and “Start” to start counting again.Tap [Reset] to reset the time duration value.
Delete Paired Vibration Alarm unit 10. Delete the Vibration Alarm unit. Tap at Nearby Devices screen to enter the Known Devices page. By tapping “Edit” and then the red minus circle, you can select “Delete” to erase any paired Vibration Alarm unit.
Preference 11) Preference setting Tap at the main screen to enter the Preference screen. You can edit and adjust the following items on this screen. 11.1 Snooze Enabled: Tap to enable/disable Snooze function. If 'Snooze Enabled' is ON, you can set: Maximum Snoozes: The number of times to repeat the snooze function. User can set Unlimited or values from 1 to 9. Snooze Duration: The time interval between snoozes. User can set from 1 to 15 minutes.
Preference 11.2 Alarm Sound Duration: The alarm duration. User can set from 1 to 15 minutes. 11.3 Auto DST update: It will adjust Daylight Saving Time (DST) automatically based on your idevice time zone setting. The alarm clock will be automatically one hour ahead of Standard Time in summer time and will be back to the normal Standard Time when back to winter time, according to your idevice’s time zone. 11.4 Tap [Done] to save the setting or Tap [Cancel] to restore the setting.
Reset the Vibration Alarm 12. Reset the Alarm If the Vibration Alarm is not working properly, press RESET button to reset the unit. During reset, the LED flashes twice in (purple) color and the Vibration Alarm vibrates twice. Then the LED will flash once per 6 seconds in red color. Reset the unit will break the connection and clear the data in your unit. Repeat step 3.3 - 3.5 to reconnect the unit.
Vibration Alarm unit
Disposal of Your Old Product Your product is designed and manufactured with high quality materials and components, which can be recycled and reused. When this crossed-out wheeled bin symbol is attached to a product it means the product is covered by the European Directive 2002/96/EC. Please inform yourself about the local separate collection system for electrical and electronic products. Please act according to your local rules and do not dispose of your old products with your normal household waste.
