User manual

• If you use an oven spray, obey the
safety instructions on the packaging.
• Do not clean the catalytic enamel (if
applicable) with any kind of detergent.
2.6 Internal light
• The type of light bulb or halogen lamp
used for this appliance is only for
household appliances. Do not use it for
house lighting.
WARNING!
Risk of electrical shock.
• Before replacing the lamp, disconnect
the appliance from the power supply.
• Only use lamps with the same
specifications.
2.7 Disposal
WARNING!
Risk of injury or suffocation.
• Disconnect the appliance from the
mains supply.
• Cut off the mains cable and discard it.
• Remove the door catch to prevent
children and pets to get closed in the
appliance.
3. PRODUCT DESCRIPTION
3.1 General overview
10
8
9
17
16
14
15
13
5
4
1
2
3
4 63 5 721
11
12
1
Control panel
2
Knob for the oven functions
3
Power lamp / symbol / indicator
4
Electronic programmer
5
Knob for the temperature
6
Temperature lamp / symbol / indicator
7
Water tank indicator
8
Water drawer
9
Heating element
10
Lamp
11
Fan
12
Aqua cleaning container
13
Shelf support, removable
14
Draining pipe
15
Water outlet valve
16
Shelf positions
17
Steam inlet
3.2 Accessories
• Wire shelf
For cookware, cake tins, roasts.
• Aluminium baking tray
For cakes and biscuits.
• Grill- / Roasting pan
To bake and roast or as pan to collect
fat.
