Reference
3. Control Settings
8
eect. If a button is congured as enc speed, it will send no MIDI messages.
3.2 Sliders and Pots
cc#
Enter CC number that you want the button to send. Valid CC numbers range from 0-119.
ch
Enter a MIDI channel that the control will send on. All controls can be set to one of 16 possible
channels.
3.3 Encoders
cc#
Enter CC number that you want the button to send. Valid CC numbers
range from 0-119.
ch
Enter a MIDI channel that the control will send on. All controls can be
set to one of 16 possible channels.
mode
This determines if the number you entered in note/CC# will be a note
or a CC message.
type
The type determines if the encoder will output a range of 0-127
(absolute) or provide increment/decrement values (relative). In relative
mode, the encoder will output a stream of values of 1 when turned to
the left, and a stream of 127 when turned to the right.
i Relative mode works with “2’s compliment” relative mode as used by
Ableton Live and Serato.
