Reference

3. Control Settings
13
Return
The pressure at which a pad generates a Note O Message (and stops streaming CC Messages).
Min: 0
Max: 1023
Default: 15
Note: Least Signicant Byte is Transmitted First.
3.9 Presets
Presets are a way of storing TWEAKER’s current settings in a le on your computer, and recall them as
needed. Preset les include both Control Settings and Global Settings. You can create any number
of presets, and even share these les with others.
i Presets are stored in your user preferences folder:
Windows: /Users/username/AppData/Roaming/Electrix/Tweaker
OS X: ~/Library/Application Support/Electrix/Tweaker
Menu
The preset menu can be used to recall or rename a preset. Click on the name to edit it, or click to the
right of the name to select a preset from the menu.
Save
Press this button to save all the current settings to the currently selected preset le for later use. If
no preset is selected (that is, the menu reads “select a preset”), then you will be prompted to enter
a name to create a preset.
Save to…
Press this button to save your settings to a new preset le. You will be prompted to enter a new
name, and the preset will be available in the menu.
Copy
Press this button to copy the currently selected preset to a new le. You will be prompted to enter
a new name, and the preset will be available in the menu. It is worth noting that if you have not
saved current changes to the controls to the preset you are copying, they will not be part of the
new preset.
