Work Light User's Manual

Design Beam 1200C
©Elation Professional • Elation Professional 6122 S. Eastern Ave. Los Angeles, Ca 90040
www.ElationLighting.com • Toll Free
(
866
)
245-6726
DMX TRAITS
16-Bit Basic Mode:
  
1 0 - 255 PAN 8-bit
2 0 - 255 PAN ne 16-bit
3 0 - 255
TILT 8-bit
4 0 - 255
TILT ne 16-bit
5 0 - 255 Color Wheel
6 0 - 255 Cyan 0 to 100%
7 0 - 255 Magenta 0 to 100%
8 0 - 255 Yellow 0 to 100%
9 0 - 255 CTO 0 to 100%
10 0 - 255 Gobo Wheel 1
11 0 - 255 Gobo Wheel 1 Index &
Continuous Scroll
12 0 - 255 Gobo Wheel 2
13 0 - 255
Rotating Effect
14 0 - 255
Focus: Continuous Adjustment
from near to far
15 0 - 255 Shutter/Strobe
16 0 - 255 Dimmer: Intensity 0 to 100%
17 0 - 255 Frost: Min. to Max. 0 to 100%
18 0 - 255 CMY Speed: Maximum to
Minimum
19 0 - 255 Pan/Tilt Speed
20 0 - 255 Color Macros
21 0 - 255 Lamp on/off, Reset, Internal
Programs
16-Bit Extended Mode:
  
1 0 - 255 PAN 8-bit
2 0 - 255 PAN ne 16-bit
3 0 - 255
TILT 8-bit
4 0 - 255
TILT ne 16-bit
5 0 - 255 Color Wheel
6 0 - 255 Color Wheel Fine 16-bit
7 0 - 255 Cyan 0 to 100%
8 0 - 255 Cyan Fine 16-bit
9 0 - 255 Magenta 0 to 100%
10 0 - 255 Magenta Fine 16-bit
11 0 - 255 Yellow 0 to 100%
12 0 - 255 Yellow Fine 16-bit
13 0 - 255
CTO 0 to 100%
14 0 - 255
CTO Fine 16-bit
15 0 - 255 Gobo Wheel 1
16 0 - 255 Gobo Wheel 1 Index &
Continuous Scroll
17 0 - 255 Gobo Wheel 1 Fine Indexing
18 0 - 255 Gobo Wheel 2
19 0 - 255 Gobo Wheel 2 Index &
Continuous Scroll
20 0 - 255 Gobo Wheel 2 Fine Indexing
21 0 - 255 Focus: Continuous
Adjustment from near to far
22 0 - 255 Focus Fine 16-bit
23 0 - 255 Shutter/Strobe
24 0 - 255 Dimmer: Intensity 0 to 100%
25 0 - 255 Dimmer Fine 16-bit
26 0 - 255 Frost: Min. to Max. 0 to 100%
27 0 - 255 Frost Fine 16-bit
28 0 - 255 CMY Speed: 0-255 Speed
Maximum to Minimum
29 0 - 255 Pan/Tilt Speed
30 0 - 255 Color Macros
31 0 - 255 Lamp on/off, Reset, Internal
Programs
