DLP® Projector – User’s Manual
– 3 –
8.
Height-adjuster button Push to release height adjuster
16
Important:
Ventilation openings on the projector allow for good air circulation, which keeps the projector lamp
cool. Do not obstruct any of the ventilation openings.
Top view—On-screen Display (OSD) buttons and LEDs
I TEM L ABEL D ESCRIPTION S EE PAGE :
1.
Keystone/
Down cursor
Corrects image-trapezoid (wider bottom) effect
Navigates and changes settings in the OSD
19
2.
VOL-/
Left cursor
Decreases volume
Navigates and changes settings in the OSD
19
Orange Lamp ready—you can safely turn on or off the projector
3.
Ready LED
Flashing Lamp not ready—do not press the power button
4.
Keystone/
UP cursor
Corrects image-trapezoid (wider top) effect
Navigates and changes settings in the OSD
19
Green Unit is powered on and working correctly
Off Unit is powered off
5.
Power LED
Flashing Operational error code
(refer to “LED Error Messages” on page 39)
6.
Enter Changes settings in the OSD
19
