User's Manual

Item
Number
Part number
Description
Material
Quantity
1
EGGM200001 - V01R01 -
Shell bottom
Bottom Cover
ABS
1
2
EGGTX025_S01G01
PCB Assembly
FR4
1
3
EGGM200002 - V01R01 -
Shell top
Upper Cover
ABS
1
4
EGG190098 - E01 -
TripleCoil
Wireless
charging coil A24
Litz wire + ferrite
1
5
EGG190098 - E02 -
Cable
2 wires cable
Copper wire
1
6
EGGM210014 -
Biadhesive
Adhesive tape -
OCS5030GP
White ash Acrylic
1
7
EGG190098 - E03 -
Connector
MOLEX
430250200.
Polarization:
PIN1: 12V - Red
PIN2: GND -
Black
Nylon
1
8
EGGM210015 - Cable
grommet
Cable grommet
Esalstomer
1
Genera l tolererance
Nominal lengths [mm] table
0.5 up to 3
±0.1
3 up to 6
±0.1
6 up to 30
±0.2
30 up to 120
±0.3
External Radius and Chamfer Height
0.5 up to 3
±0.2
3 up to 6
±0.5
Angular dimension
up to 10
±1°
over 10 up to 50
±0°30’
over 50 up to 120
±0°20’
