USER MANUAL

EGG200062

Triple coil embedded system 10W

Product overview

The “Triple coil embedded system” is a wireless charging module designed to be

integrated in any surface. Using the provided adhesive mounting tape, it can be

installed under slim surfaces (maximum 5 mm thickness). No need for screws: the

installation process is quick and easy, and the charger can be removed without

damaging the top. The “Triple coil embedded system” is Qi certiﬁed and works

with any Qi-certiﬁed device. A triple-coil system ensures high positioning

freedom. Maximum power delivered is 10W.

How to use

1. Remove the layer on the adhesive mounting tape.

2. Apply under surface. Works with most non-metal surfaces.

3. Connect the cable to the power source.

4. Lay down any Qi-enabled smartphone on the wireless charging area to

start charging.

Features

● Certiﬁed with WPC Qi 1.2.4

● Designed for integration: a completely hidden solution

● Industrial adhesive mounting tape, no need for screws

● Quick and practical installation process, easy charger removal without

damaging the top

● Maximum power 10W

Summary of content (6 pages)

PAGE 1
USER MANUAL EGG200062 Triple coil embedded system 10W Product overview The “Triple coil embedded system” is a wireless charging module designed to be integrated in any surface. Using the provided adhesive mounting tape, it can be installed under slim surfaces (maximum 5 mm thickness). No need for screws: the installation process is quick and easy, and the charger can be removed without damaging the top. The “Triple coil embedded system” is Qi certified and works with any Qi-certified device.
PAGE 2
● ● ● Triple coil free positioning technology allows wider charging area compared to standard solutions Designed to be installed under surfaces with maximum thickness of 5 mm (0.19 in) Designed in two variants: ● Variant 01: two power input lines ● Variant 02: two power input lines and one output Status Signal (SS). The SS is controlled by the system and its function is to indicate if a device is in charge (3.
PAGE 3
Technical drawings Variant 01: Triple coil embedded system 2 pin
PAGE 4
Item Number Part number Description Material Quantity 1 EGGM200001 - V01R01 Shell bottom Bottom Cover ABS 1 2 EGGTX025_S01G01 PCB Assembly FR4 1 3 EGGM200002 - V01R01 Shell top Upper Cover ABS 1 4 EGG190098 - E01 TripleCoil Wireless charging coil A24 Litz wire + ferrite 1 5 EGG190098 - E02 Cable 2 wires cable Copper wire 1 6 EGGM210014 Biadhesive Adhesive tape OCS5030GP White ash Acrylic 1 7 EGG190098 - E03 Connector MOLEX 430250200.
PAGE 5
Safety information Please read this safety information carefully before using the product to prevent injury to yourself or others and damage to your device. Please keep this manual for future reference. ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● Do not damage the cable. Doing so may cause electric shock or fire. Keep the product away from hot surfaces and sharp corners. Do not carry or drag the product by the cable. Do not use the product if one or more of its components are damaged or faulty.
PAGE 6
Limited warranty For product warranty visit our website at the page www.eggtronic.com/support/download-area This product is meant for use only with appropriate devices. Please consult your device packaging to determine whether this product is compatible with your particular device. Manufacturer will not be responsible for any damages you or any third party that may suffer as a result of use, intended or unintended, or misuse of this product.
