User's Manual

6
1-5 Familiar with your new wireless broadband router
Front Panel
LED Name
Light Status
Description
PWR
On
Router is switched on and correctly powered.
Off
Router is switched off.
WLAN
On
Wireless WPS function is enabled.
Off
Wireless network is switched off.
Flashing
Wireless LAN activity (transferring or receiving data).
WAN
10/100M
On
WAN port is connected.
Off
WAN port is not connected.
Flashing
WAN activity (transferring or receiving data).
LAN 1-4
10/100M
LNK/ACT
On
LAN port is connected.
Off
LAN port is not connected.
Flashing
LAN activity (transferring or receiving data).
WAN
1000M
On
WAN port is connected and running at 1000Mbps.
Off
WAN port is not connected.
Flashing
WAN activity (transferring or receiving data at
1000Mbps).
LAN 1-4
1000M
LNK/ACT
On
LAN port is connected and running at 1000Mbps.
Off
LAN port is not connected.
Flashing
LAN activity (transferring or receiving data at
1000Mbps).
