A FAQ
How do I configure the Router to access Internet by ADSL users?
1. First, configure the ADSL Modem configured in RFC1483 bridge model.
2. Connect the Ethernet cable from your ADSL Modem to the WAN port on
the Router. The telephone cord plugs into the Line port of the ADSL
Modem.
3. Login to the Router, click the “Network” menu on the left of your
browser, and click "WAN" submenu. On the WAN page, select “PPPoE”
for WAN Connection Type. Type user name in the “User Name” field and
password in the “Password” field, finish by clicking “Connect”.
Figure 107: PPPoE Connection Type
4. If your ADSL lease is in “pay-according-time” mode, select “Connect on
Demand” or “Connect Manually” for Internet connection mode. Type an
appropriate number for “Max Idle Time” to avoid wasting paid time.
Otherwise, you can select “Auto-connecting” for Internet connection
mode.
Figure 108: PPPoE Connection Mode
N OTE : Sometimes the connection cannot be disconnected although you
specify a time to Max Idle Time, since some applications is visiting the
Internet continually in the background.
N OTE : If you are a Cable user, please configure the Router following the
above steps.
