User's Manual

C HAPTER 14 | System Tools
Local Management
– 111 –
LOCAL MANAGEMENT
Choose menu “Security->Local Management”, you can configure the
management rule in the screen as shown in the following figure. The
management feature allows you to deny computers in LAN from accessing
the Router.
Figure 105: Local Management
Table 3: Statistics Table
IP/MAC Address The IP/MAC Address displayed with statistics
Total Packets The total amount of packets received and transmitted by the
Router.
Bytes The total amount of bytes received and transmitted by the
Router
Current Packets The total amount of packets received and transmitted in the
last Packets Statistic interval seconds.
Bytes The total amount of bytes received and transmitted in the last
Packets Statistic interval seconds.
ICMP Tx The total amount of the ICMP packets transmitted to WAN in
the last Packets Statistic interval seconds.
UDP Tx The total amount of the UDP packets transmitted to WAN in
the last Packets Statistic interval seconds.
TCP SYN Tx The total amount of the TCP SYN packets transmitted to WAN
in the last Packets Statistic interval seconds.
