RULES LIST
Choose menu “QoS->Rules List”, you can view and configure the QoS rules
in the screen below.
Figure 92: QoS Rules List
Description - This is the information about the rules such as address
range.
Egress bandwidth - This field displays the max and mix upload
bandwidth through the WAN port, the default is 0.
Ingress bandwidth - This field displays the max and mix download
bandwidth through the WAN port, the default is 0.
Enable - This displays the status of the rule.
Modify - Click Modify to edit the rule. Click Delete to delete the rule.
To add/modify a QoS rule, follow the steps below.
1. Click the Add New buttonshown in Figure 91, you will see a new screen
shown in Figure 92.
2. Enter the information like the screen shown below.
3. Click the Save button.
Figure 93: QoS Rule Settings
