13 QOS SETTINGS
There are two submenus under the QoS menu: QoS Settings and Rules
List. Click any of them, and you will be able to configure the corresponding
function. The detailed explanations for each submenu are provided below.
QOS SETTINGS
Choose menu “QoS->QoS Settings”, you can configure the Egress
Bandwidth and Ingress Bandwidth in the next screen. Their values you
configure should be less than 100000Kbps. For optimal control of the
bandwidth, please select the right Line Type and ask your ISP for the total
bandwidth of the egress and ingress.
Figure 91: QoS Settings
◆ Enable QoS - Check this box so that the QoS settings can take effect.
◆ Line Type - Select the right type for you network connection. If you
don’t know how to choose, please ask your ISP for the information.
◆ Egress Bandwidth - The upload speed through the WAN port.
◆ Ingress Bandwidth - The download speed through the WAN port.
