12 ADVANCED ROUTING
STATIC ROUTING LIST
Choose menu “Advanced Routing”, you can configure the static route in the
next screen. A static route is a pre-determined path that network
information must travel to reach a specific host or network.
Figure 89: Static Routing
To add static routing entries:
1. Click the Add New button.
Figure 90: Add or Modify a Static Route Entry
2. Enter the following data:
Destination IP Address - The Destination IP Address is the address
of the network or host that you want to assign to a static route.
Subnet Mask - The Subnet Mask determines which portion of an IP
Address is the network portion, and which portion is the host portion.
Gateway - This is the IP Address of the gateway device that allows for
contact between the Router and the network or host.
