User's Manual

Patient Monitor User Manual Basic Operation
- 22 -
14 Shortcut key area
15 Scroll left to display more shortcut keys
16 Mute key
17 Parameter waveform
3.2.1 Using Keys
The monitor has four different types of keys:
3.2.1.1 Permanent Keys
A permanent key is a graphical key that remains on the screen all the time to give you fast access
to functions.
Menu – enter the main setup menu.
Mute key – close the audio alarm to switch off the alarm.
3.2.1.2 Shortcut Keys
A shortcut key is a configurable graphical key, located at the bottom of the main screen. It gives
you fast access to functions. The selection of shortcut keys available on your monitor depends on
your monitor configuration and on the options purchased.
Perform a 12-lead analysis
Switch to the standard screen
Exit from 12-lead analysis
Switch to the OxyCRG screen
Access the 12-lead review
Switch to the large font screen
Perform 12-lead record Set the module switch
Admit a patient
Change the key volume
Review the trend graph
Adjust the screen brightness
