User's Manual

Patient Monitor User Manual Product Specification
- 178 -
Unit kPa, mmHg
Measuring range
Art 0 to 300 mmHg
PA -6 to +120mmHg
CVP/RAP/LAP/ICP -10 to +40 mmHg
P1/P2 -50 to +300 mmHg
Resolution 1 mmHg
Accuracy (without sensor)
r 2 % or 1 mmHg, whichever is greater
A.10 CO
2
EDAN Module
Intended patient Adult, pediatric, neonatal
Measurement
method
Non-dispersive infrared gas analysis (NDIR)
Unit mmHg, %, kPa
CO
2
0 mmHg ~ 150 mmHg (0 % ~ 20%)
Measuring Range
AwRR 2 rpm ~ 150 rpm
EtCO
2
0.2mmHg (0 mmHg~ 70mmHg), 0.5mmHg (70 ~ 100mmHg)
FiCO
2
0.2mmHg
Resolution
AwRR 1rpm
r 2 mmHg, 0mmHg ~ 40
mmHg
r 5% of reading, 41 mmHg ~
70 mmHg
r 8% of reading, 71 mmHg ~
100 mmHg
r 10% of reading, 101 mmHg
~ 150 mmHg
Typical conditions:
Ambient temperature: 25
r 3ć
Barometric pressure: 760
r 10
mmHg
Balance gas: N
2
Respiratory rate: not exceed
60rpm
Sample gas flowrate:
100ml/min
EtCO
2
r12% or r 4 mmHg of
reading, whichever is greater
All conditions
Accuracy
AwRR
r 1 rpm
Sample gas
Flowrate
70ml/min or 100ml/min, optional (
r15ml/min)
