A.6 SpO
2
EDAN Module
Measurement Range 0 ~ 100 %
Resolution 1 %
Accuracy
r2 % (70%~100% SpO
2
)
Adult (including Pediatric)
Undefined (0~69% SpO
2
)
r3 % (70%~100% SpO
2
)
Neonate
Undefined (0~69% SpO
2
)
Pulse Rate
Measuring Range 25bpm ~ 300bpm
Resolution 1bpm
Accuracy
r2bpm
Data update period 1s
Wave length: Red light: 660r3 nm;
Infrared light: 905
r5 nm
Sensor
Emitted light energy: <15mW
Nellcor Module
Measuring Range 1% ~ 100%
Resolution 1%
Data update period 1s
Sensor Type Accuracy
Accuracy
DS-100A, OXI-A/N
r 3%(70% ~ 100% SpO
2
)
* When the sensor is used to neotate as recommendation, the specified accuracy range of the
neotate is always higher ±1 than adult.
Pulse Rate
Measuring Range 20bpm ~ 300bpm
Resolution 1bpm
Accuracy
r 3bpm (20bpm ~ 250bpm)
Wave length: approximately 660 and 900nm Sensor
Emitted light energy: <15mW
