User's Manual

Patient Monitor User Manual Product Specification
- 167 -
iM80 Display screen: 15 inch color TFT,
supporting touch screen
Resolution: 1024 × 768
A maximum of 13 waveforms
One power LED
Two alarm LED
One charge LED
A.2.4 Battery Specification
2.1Ah 180 min or longer iM50
4.2Ah 420 min or longer
One battery (4.2Ah) 120 min or longer iM80
Two batteries (2*4.2Ah) 240 min or longer
2.1Ah 150 min or longer
Operating Time
iM60/iM70
4.2Ah 300 min or longer
Condition
At 25
qC, with (a) new fully charged battery/batteries, continuous SpO
2
measurement and NIBP automatic measurement mode at interval of 15
minutes, ECG/TEMP module connected, recording at interval of 10
minutes, brightness set to “1”
2.1Ah 200 min or shorter iM50
4.2Ah 380 min or shorter
One battery (4.2Ah) 320 min or shorter iM80
Two batteries (2*4.2Ah) 560 min or shorter
2.1Ah 200 min or shorter
Charge Time
iM60/iM70
4.2Ah 360 min or shorter
Condition Monitor is on or in standby mode.
A.2.5 Recorder
Record Width 48 mm
Paper Speed 25 mm/s, 50 mm/s
Trace 3
Recording types Continuous real-time recording
8 seconds real-time recording
Time recording
