PADECG User Manual Technical Specifications
- 39 -
Relative Humidity:
15%RH ~ 95%RH
Non-Condensing
15%RH ~ 95%RH
Non-Condensing
Atmospheric Pressure:
70 kPa ~ 106 kPa
70 kPa ~ 106 kPa
A1.3 Physical Specifications
Dimensions
DX12(iOS) Transmitter:
63mm(L)×107mm(W) ×23mm(H) (2.5in×4.2in×0.9in)
Weight
DX12(iOS) Transmitter:
Approx. 113g (not including battery)
A1.4 Power Supply Specifications
Power Supply:
DX12(iOS) Transmitter:
Input Power: 2×1.5V Excell Alkaline AA IEC LR6;
Operation life of battery≥12 hours
A1.5 Performance Specifications
HR Recognition
HR Range:
30 bpm ~300 bpm
Accuracy:
1 bpm
Filter
(PADECG Analysis Software)
AC Filter: 50Hz/60Hz/Off
DFT Filter: 0.32Hz (weak) /0.67Hz (strong) /0.05Hz
EMG Filter: 25Hz/35Hz/45Hz/Off
Lowpass Filter: 150Hz/100Hz/75Hz/Off
DX12(iOS) Transmitter Performance
Leads Mode:
12 standard leads
Acquisition Mode:
Simultaneously 12 leads
A/D:
18 bits
Resolution:
2.52uV/LSB
Sample Frequency:
10,000 /sec/channel (sampling)
500 /sec/channel (analysis)
