PADECG User Manual Introduction
- 11 -
2.1.2.1 Keys and Icons
Main Screen Menu Screen
Keys/Icons
Description
After batteries are installed, press this key to turn on/off DX12(iOS)
Transmitter.
When the Menu screen is displayed, press this key to return to the previous
screen.
When the Main or Menu screen is displayed, press this key to enter the next
menu.
Press this key, and then press in 1.2 seconds to lock / unlock the
keypad.
When the Main screen is displayed, press this key to switch the lead.
When the Menu screen is displayed, press this key to display an item in black.
Icon for Bluetooth Connection
If this icon is not displayed on the main screen, you need to match the device
manually.
Icon for Keypad Locked
If no operation is taken, the Main screen will be displayed and the keyboard
will be locked automatically in 8 seconds.
Icon for Battery Capacity
When the battery is weak, a hint will be displayed in PADECG software.
