Users Manual

____________________________________________________________________________________
SR200 IFU v1 Page 2
1.3 Product Description
Front View Rear View
Figure 1. Front and Rear views of Smart Repeater (SR200)
1.4 Product Specification – Smart Repeater SR200
Item Specification
Connectivity
2.4GHz Bluetooth (BLE) for both sending and
receiving
Transmission Range Up to 20 meter
Operating Time
Up to 10 hours* (with Battery) for repeater
function
Charging Time Less than 2 minutes to fully charge up ECPIN
Rating Power
1 AAA cell Battery
or external USB power DC =5V 500mA;
Multi-probe Support
OS for Software APP
iOS version 10.3.3 or above;
Android version 6.0 or above
*The operating time depends upon the type of battery used. It is recommended to use alkaline battery.
LED
Magnets
Battery Door
Power Source
Selector
Micro USB
Socket
Lid
