Specifications

4
Introducing the Motherboard
• AMD 760G (RS780L) & AMD SB710
• Socket AM3+ for AMD AM3+ FX
TM
/ Phenom
TM
II /Athlon
TM
II/
Sempron
TM
100 Series processors
• Supports 125W Phenom
TM
II X6 processors
• Supports “Hyper-Threading” technology CPU
• 2 x 240-pin DDR3 DIMM sockets support up to 16 GB
• 1 x PCI Express x16 slot
• 1 x PCI Express x1 slot
• 2 x PCI slots
• Supported by AMD SB710 Express Chipset
• 6 x Serial ATA 3.0 Gb/s Host Controllers
• RAID 0, RAID 1, RAID 10 Configuration
• VIA VT1705 6-ch High Definition audio CODEC
• Compliant with HD audio specification
• Realtek RTL8111E Gigabit LAN
• 1 x PS/2 keyboard & PS/2 mouse connector
• 4 x USB 2.0 ports
• 1 x Serial port (COM)
• 1 x HDMI port (or DVI port)
• 1 x VGA port
• 1 x RJ45 LAN connector
• 1 x Audio port (Line in, microphone in and line out)
Chipset
Memory
Expansion
Slots
Storage
Audio
LAN
Rear Panel I/O
CPU
Specifications
• 1 x 24-pin ATX Power Supply connector
• 1 x 8-pin 12V connector
• 1 x 4-pin CPU_FAN connector
• 1 x 3-pin SYS_FAN connector
• 6 x SATA 3Gb/s connectors
• 2 x USB 2.0 headers support additional 4 USB ports
• 1 x Front panel header
• 1 x Chassis Intrusion Detect header
• 1 x SPDIF out header
• 1 x Front panel audio header
• 1 x Speaker header
• 1 x parallel port header (LPT)
• 1 x CD IN header
• 1 x CLR_CMOS header
• 1 x IDE connector
Internal I/O
Connectors &
Headers
Due to AMD CPU spec limitation, please refer to Memory QVL
on ECS website for more information.
• On Chip (AMD 760G-based with ATI
TM
Radean HD3000
graphics)
• Integrated DirectX 10 graphics processor
• Share memory maximum update to 512MB
Graphics
• Supports Dual-Channel DDR3 up to 1866 with AM3+ CPU
• Supports Dual-Channel DDR3 1333 / 1066 with AM3 CPU
