Setting Up AMD RAID Configuration
The BIOS CMOS Setup Utility screen appears.
Setting Up a bootable RAID Array
This section explains how to configure a bootable AMD RAID array.
Setting Up the BIOS
Figure 1.2 SATA Configuration Screen
Use the arrow keys to select the SATA Configuration (see Figure 1.2) and globally
set SATA Mode to RAID.
Start your computer, then press Delete to enter the BIOS setup.
Figure 1.1 BIOS CMOS Setup Utility Main Screen
1
3
Chapter 5
Setting Up AMD SB710 RAID Configuration
SATA Configuration
Serial-ATA Controller [Enhanced]
SATA Mode [IDE Mode]
SATA Master Not Present
SATA Slave Not Present
SATA Port1 Not Present
SATA Port2 Not Present
SATA Port3 Not Present
SATA Port4 ST32000641AS (2000.3G
SATA Port5 Not Present
SATA Port6 Not Present
Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
Version 2.11.1210. Copyright (C) 2011, American Megatrends, Inc.
+/- : Change Opt.
lk
:Select Screen
F1:General Help
F2:Previous Values
F3:Optimized Defaults
F4:Save & Exit
mn
:Select Item
/Click
Enter / Dbl Click: Select
ESC/Right Click:Exit
Main Advanced Chipset M.I.B.III Boot Security Save & Exit
Select Advanced icon and press Enter (or double click it).
2
Serial-ATA Controller
