Installing the Motherboard

SPDIFO: SPDIF out header

This is an optional header that provides an S/PDIF (Sony/Philips Digital Interface)

output to digital multimedia device through optical fiber or coaxial connector.

2 +5VA 5V analog Power

3 Key No pin

4 GND Ground

1 SPDIF SPDIF digital output

Pin Signal Name Function

CASE: Chassis intrusion detect header

This detects if the chassis cover has been removed. This function needs a chassis

equipped with instrusion detection switch and needs to be enabled in BIOS.

Pin 1-2 Function

Short Chassis cover is removed

Open Chassis cover is closed

CD_IN: Analog audio input header

1 CD_L Left CD-in signal

2 GND Ground

3 GND Ground

4 CD_R Right CD-in signal

Pin Signal Name Function
