2. Package Contents and Technical Specifications
2.3 Product Diagram
Robot
Remote Control
1. Status Indicator Light and
START/PAUSE Button
2. Handle
3. Power Cord
4. Power Switch
5. Cleaning Pad
6. Driving Treads
7. Wheel Sensor
8. Bottom Status Indicator Light
9. Fan
10. Edge Detection Sensors
11. Suction Sensor
RESET
1
2
3
6
4
5
1. RESET Button
2. Direction Control Buttons
3. START/PAUSE Button
4. “N” Cleaning Mode Button
5. “Z” Cleaning Mode Button
6. Remote Control Pairing Button
N Z
