EN Instruction Manual
Congratulations on the purchase of your ECOVACS ROBOTICS WINBOT! We hope it brings you many years of satisfaction. We trust the purchase of your new robot will help keep your home clean and provide you with more quality time to do other things. Before you go any further, please register your product on the ECOVACS ROBOTICS website at www.ecovacsrobotics.com/registration/. We also suggest you record your model number, serial number, date of purchase and attach your receipt to this page for safekeeping.
Contents 1. Important Safety Instructions.......................................................................2 2. Package Contents and Technical Specifications.......................................4 2.1 Package Contents.....................................................................................4 2.2 Specifications............................................................................................4 2.3 Product Diagram.......................................................................
1. Important Safety Instructions When using an electrical appliance, basic precautions should always be followed, including the following: READ ALL INSTRUCTIONS BEFORE USING THIS APPLIANCE. SAVE THESE INSTRUCTIONS 1. This Appliance is not intended to be used by children under 8 or anyone lacking knowledge on proper use. Supervision may be necessary. Do not allow children to play with the Appliance. 2. Do not use the Appliance in extremely hot or cold environments (below 0˚C/32˚F or above 40˚C/104˚F).
1. Important Safety Instructions 21. The Back-Up Battery must be replaced by the manufacturer or its service agent in order to avoid a hazard. 22. The Back-Up Battery must be removed and discarded according to local laws and regulations before disposal of the Appliance. 23. The Appliance must be disconnected from the receptacle before removing the battery for disposal of the Appliance. 24. Please dispose of used batteries according to local laws and regulations. 25.
2. Package Contents and Technical Specifications 2.1 Package Contents Robot Power Adapter Instruction Manual Safety Pod and Tether (3) Cleaning Pads WINBOT Cleaning Solution (1) WINBOT Extension Cord (1.5m/4’11”) Finishing Cloth Remote Control with Batteries 2.2 Specifications Model W830 Working Voltage 24V DC Rated Power 75W Remote Control Input Voltage 3V DC Power Adapter:EA10952E Input: 100-240V AC 50/60Hz 2.5A Output: 24V DC 3.
2. Package Contents and Technical Specifications 2.3 Product Diagram Robot 5 6 1 7 8 11 9 2 3 10 4 1. Status Indicator Light and START/PAUSE Button 2. Handle 3. Power Cord 4. Power Switch 5. Cleaning Pad 6. Driving Treads 7. Wheel Sensor 8. Bottom Status Indicator Light 9. Fan 10. Edge Detection Sensors 11. Suction Sensor Remote Control 1 RESET 2 3 N Z 1. RESET Button 2. Direction Control Buttons 3. START/PAUSE Button 4. “N” Cleaning Mode Button 5. “Z” Cleaning Mode Button 6.
3. Operating the Robot 3.1 Notes Before Cleaning 50 50 Do not use WINBOT 8 on a framed window with a frame smaller than 5mm (0.2”). WINBOT 8 can clean framed or frameless glass, larger than 50cm x 50cm (19.7’’ x 19.7’’). If WINBOT 8’s Status Indicator Light flashes If the window is covered with dirt, clean a GREEN after powering ON, the Back-Up small area on the glass before use and place Battery requires charging. Keep WINBOT WINBOT 8 there.
3. Operating the Robot 3.2 Attach the Cleaning Pad Turn WINBOT 8 over and attach the Cleaning Pad to the Velcro smoothly. The white side of the Cleaning Pad attaches to the Velcro, and the grey microfiber side faces out. Make sure the Cleaning Pad is placed exactly within its Velcro area and does not cover the Fan or Edge Detection Sensors. 3.3 Assemble the Power Adapter 3.
3. Operating the Robot 1 Loop one end of the Safety Tether to End A on the Robot Power Cord and tighten. 2 Connect End A and End B and tighten. 3 Loop the other end of the Safety Tether around the Safety Pod’s channel and pull it tight. * If the length of the power cord restricts WINBOT 8’s movement, a WINBOT Extension Cord can be used. Disconnect End A and End B, and connect them with both ends of the Extension Cord respectively and tighten. * Only one Extension Cord can be used with WINBOT 8.
3. Operating the Robot 3.5 Place the Safety Pod Wipe the surface of the Safety Pod’s suction cup clean with the provided Finishing Cloth. If WINBOT 8 is being used to clean an inside window: Press the Safety Pod FIRMLY on the top corner of the inside window. Make sure the Safety Pod is attached securely in place. If WINBOT 8 is being used to clean an outside window: Press the Safety Pod FIRMLY on the inside of the window being cleaned. Make sure the Safety Pod is attached and securely in place. 3.
3. Operating the Robot 3.7 Start 1 Plug in WINBOT 8 2 Power ON Move the Power Switch to the “ ” position. WINBOT 8 is powered ON when the Status Indicator Light flashes BLUE. * Keep objects away from WINBOT 8’s Fan to avoid blockage. 3 Place on the Glass Place WINBOT 8 on the window at least 10cm (4”) from window corners or other obstacles. WINBOT 8 has successfully attached to the window when the Status Indicator Light glows a continuous BLUE. * Please ensure there is a 15cm (5.
3. Operating the Robot 4 Start Press the START/PAUSE button on WINBOT 8 or on the Remote Control to begin cleaning. To change Cleaning Modes, Pause WINBOT by pressing the START/PAUSE button on WINBOT 8 or on the Remote Control, then press the “Z” or “N” Cleaning Mode Button on the Remote Control. “N” Cleaning Mode is the default Cleaning Mode and is also ideal for tall windows. “Z” Cleaning Mode is best for wide windows. * Do not unplug WINBOT 8 while it is cleaning. 3.
3. Operating the Robot 3.9 Stop When WINBOT 8 completes its cleaning cycle, it returns to the place it started and beeps. 1 Remove WINBOT 8 Grasp WINBOT 8’s Handle. Press and hold for approximately 5 seconds and the fan will stop. Remove WINBOT 8 from the window. Polish away any marks left on the glass from WINBOT’s removal with the provided Finishing Cloth. 2 Power OFF Move the Power Switch to the “o” position. OFF 3 Remove the Safety Pod.
4. Maintenance Before performing cleaning and maintenance on WINBOT 8, move the Power Switch to the “o” position and unplug it from the receptacle. 4.1 Cleaning Pad Turn the robot over and remove the Cleaning Pad. Soak the Cleaning Pad in cool, clean water for 2 minutes. Hand wash with mild detergent and lay flat to dry. Allow it to dry completely before re-attaching it to the robot. * Do NOT use a wet Cleaning Pad on WINBOT 8 or it may slip on the window.
4. Maintenance 4.3 Driving Treads Move the Power Switch to the “I” position. Press and hold the robot’s START/PAUSE Button for 5 seconds to stop the Fan. Turn WINBOT 8 over. Inspect the Driving Treads by using the and buttons on the Remote Control. Stop the Driving Treads if dirt is seen on the Treads. Move the Power Switch to the “O” position. Clean any dirt on the Driving Treads with the provided Finishing Cloth.
5. Status Indicator Light and Sound Indicator Description Status Indicator Light flashes GREEN Back Up Battery is low and is charging. WINBOT will not clean until the Back-Up Battery is properly charged. Status Indicator Light flashes BLUE WINBOT 8 is powered ON and is ready to be placed on the glass. Status Indicator Light glows a continuous BLUE WINBOT 8 has successfully adhered itself to the glass and is ready to clean. Status Indicator Light flashes RED WINBOT 8 has a problem.
6. Troubleshooting NO. 1 2 16 EN Malfunction Remote Control does not work Status Indicator Light flashes BLUE after WINBOT 8 is placed on the glass Possible Causes Solutions WINBOT 8 is cleaning. When WINBOT 8 is cleaning, only the START/PAUSE Button works on the Remote Control. Pause WINBOT 8 by pressing the START/PAUSE button on the robot or Remote Control. Other buttons on the Remote Control will function when WINBOT 8 is paused. The Remote Control is not paired with WINBOT 8.
6. Troubleshooting NO. 3 4 Malfunction Possible Causes Solutions Interruption of electricity while WINBOT 8 was cleaning due to power failure, plug displacement, or loose connection to the Power Adapter. A. Connect WINBOT 8 to the Power Adapter and plug into the wall receptacle. Press START/ PAUSE Button on the robot or on the Remote Control. WINBOT 8 will resume cleaning. B.
6. Troubleshooting NO. 5 18 EN Malfunction WINBOT 8 gets stuck in a corner or near the edge of the window, and cannot be directed using the Remote Control. Possible Causes Solutions Not enough suction or Edge Detection Sensor malfunction. A. Press the RESET Button on the Remote Control. B. If WINBOT 8 does not Reset, it must be placed in Manual Override Mode. Hold the RESET Button on the Remote Control until the Status Indicator Light glows a continuous RED.
Designed and Manufactured by/Conception et Fabrication par ECOVACS ROBOTICS, Co., Ltd . Made in China/Fait en Chine Distributed by/Distribué par ECOVACS ROBOTICS, Inc. Canton, OH, USA/Canton, OH, É.-U.
