Softener Components
Key
No.
Part No. Description
1 7337296 Top Cover (order decal below)
¢
7316703 Faceplate Decal
2 7331818 Repl. Electronic Control Board (PWA)
3 7337482 Power Supply, 28V DC
4 7225499 Locking Plate
– 7112963
Distributor O-Ring Kit
(includes Key Nos. 5-7)
5
á
O-Ring, 73.0 mm x 82.6 mm
6
á
O-Ring, 20.6 mm x 27.0 mm
7
á
O-Ring, 69.9 mm x 76.2 mm
8 7077870 Top Distributor
– 7331177
Tank Neck Clamp Kit
(includes 2 ea. of Key Nos. 9 & 10)
9
á
Clamp Section (2 req.)
10
á
Retainer, Clamp (2 req.)
11 7105047 Repl. Bottom Distributor
12 7328904 Repl. Resin Tank, 22.9 cm x 88.9 cm
13 0502272 Resin, 28.3 liters (1 cu. ft.)
Key
No.
Part No. Description
14 7155115 Cover, Brinewell
15 7338145 Brinewell
– 7331981
Brinewell Mounting Hardware Kit
(includes Key Nos. 16 & 17)
16
á
Wing Nut, 1/4-20
17
á
Screw, 1/4-20 x 1.6 cm
18 7250884 Salt Lid (order decal below)
¢
7317301 Instruction Decal
19 7337424 Brine Tank
– 7331258
Overflow Hose Adaptor Kit
(includes Key Nos. 20-21)
20
á
Grommet
21
á
Adaptor Elbow
22
á
Hose Clamp
23 7310202 Brine Valve Assembly
24 7327568 Float, Stem & Guide Assembly
25 7139999 Drain Hose, 6 meters
26 7129871
Bypass Valve Assembly, 3/4”, in -
cluding 2 O-Rings (See Key No. 71)
