Installation & Assembly
Table Of Contents
PAGE 2
B
DETAIL B
SCALE 1 : 4
HANGBAR BRACKET
5/16"-18 X 1/2" LONG
HEX HEAD BOLT
4
WITH TWO PEOPLE, CAREFULLY LIFT AND
CENTER STEP 3 ONTO THE K40 RACK.
ASSEMBLE AS SHOWN IN 4 PLACES.
SCREW IN THE BOLTS AND TIGHTEN WITH
PROVIDED ALLEN KEY
K49 LOWER UPRIGHT
QTY. 2
FROM STEP
1
3
TAKE ASSEMBLED HANGBAR
FROM STEP 1 AND INSERT IT INTO
THE K49 LOWER UPRIGHTS.
