Removal:
There are two methods to removing the Garage Door Controller from a Z-Wave network: exclusion and
performing a factory reset (see section on Factory Reset).
1. Follow the Z-Wave controller’s instructions on putting the Z-Wave controller into removal/exclusion
mode.
2. Locate and press the hub button.
3. Device’s status indicator will blink red and beep three times to indicate successful removal.
Mounting and Connections to Garage Door Opener
Mount the tilt sensor to the top panel of the garage door. Mount the Garage Door Controller to the garage
door opener’s hardware using the included mounting bracket. Alternatively, you can mount the Garage Door
Controller on the ceiling near the garage door opener and the power outlet. Connect the Garage Door
Controller’s relay switch wires to the pushbutton wall console terminals on the garage door opener. Make
sure not to disconnect any wires that are already connected to the garage door opener.
Factory Reset
Please use this procedure only when the network primary controller is missing or otherwise inoperable.
Factory resetting the Garage Door Controller will default it to factory settings and reset the tilt sensor pairing
to the original tilt sensor.
1. Locate the reset button.
2. Insert a paperclip into the hole until you feel the button depress. There will be a short beep.
3. Hold the button down for ten seconds. The status indicator will blink red while the reset button is
pressed and will go out after ten seconds.
4. The device’s status indicator will turn green when the reset operation is complete. The device is now
ready to be added to a Z-Wave network.
Note: Factory reset only works when the device is already added into a Z-Wave network. If the Garage Door
Controller is not included in a network, then it cannot be factory reset.
Adding a Tilt Sensor
The Garage Door Controller pairs with the tilt sensor to monitor the state of the garage door.
The original (included with the Garage Door Controller) tilt sensor does not need to be added. To add a
different Ecolink ClearSky tilt sensor:
1. Locate and press the tilt button. There will be a short beep.
2. Remove pull-tab from the tilt sensor or reinsert the battery into the tilt sensor.
3. If pairing is successful, the device’s warning light will blink white and beep for one second.
