Music Driving On To make driving a better and more enjoyable experience. That’s always been ECLIPSE’s mission since we started crafting mobile electronics over half a century ago. We focus on creating products that communicate the passion and emotion in music. Today ECLIPSE also manufactures in-car visual entertainment along with multichannel sound to create extraordinary in-car theater products.
Introduction 2 AVN VN Series 4 AVX VX Series 12 CD Receivers 14 Peripheral Equipment 22 Amplifiers 24 Speakers 28 3
In a class all its own. The full-featured AVN7000 installs easily for a sophisticated look and does not require any hideaway units for operation. With a sleek, stylish design, the AVN7000 enhances any car interior.
HDD Series AVN is the innovative ECLIPSE concept that integrates audio, visual and navigation into clean, stylish designs that grace any car interior. AVN7000 AVN5495 HDD Navigation System with 7˝ Wide TFT Display and DVD/MS Multi-Source Receiver ESN E5 6.5˝ Wide TFT Touch-Panel Display CD/DVD/MS Multi-Source Receiver with HDD Navigation A true feat of engineering, the AVN7000 includes a 20GB HDD, 7˝ display and all required circuitry in a single DIN configuration that installs easily.
DVD Series DVD-based AVN products offer the benefits of dual-disc mechanisms for versatile entertainment to please all car occupants as well as feature leading navigation technologies, creating an extremely desirable product category. AVN6600 AVN5500 DVD Navigation System with 6.5˝ Wide TFT Display and Dual-DVD Multi-Source Receiver DVD Navigation System with 6.5˝ Wide TFT Display and DVD Multi-Source Receiver The AVN6600 allows flexible operation as it is equipped with two DVD playing mechanisms.
High-performance audio functions and features DCU105 Audio Video Matrix Dolby Digital 5.1 ch. dts 5.1 ch. Partners the AVN7000 to provide 5.1ch. surround sound for surround-encoded material as well as upmixing 2-channel sources to surround. Also expands connectivity and flexible routing of multiple program sources. Dolby Pro Logic II Time Alignment Pro Crossover Pro Parametric EQ Pro DCU105 AV Matrix Selector 5.1ch.
System setups AVN7000 + DCU105 Adding a DCU105 to the AVN7000 instantly opens up a wealth of system expansion possibilities that satisfy all occupants in a car with personalized entertainment options.
AVN6600/AVN5495/AVN5500 + MRE-700W For the above-listed AVN products, adding the RAS-100 AV Matrix enables putting together an ideal rear seat entertainment system with full routing and switching capabilities. MRE-700 WHP-100 MRE-700 RAS-100 WHP-100 Routing program material signals from the RAS-100 through the AVN6600. Program material signals routed from the AVN6600 to the RAS-100.
Features List Media HDD DVD CD Memory Stick Navigation Navi Device HDD Navigation DVD Navigation Ultima Engine Displaying Display Split screen Street name Point-of-Interest (POI) Street map Operation Touch panel control Searching Address search POI Name POI Category Emergency search Memory search Previous search Map search Intersection search Freeway search (ENTER/EXIT) Coordinates search Telephone number search Home search Quick access point search Routing 3 routes information Detours Enroute stopping poi
AUDIO DVD DVD-Video DVD-R/RW, DVD+R/RW *2 Dolby Digital 5.1ch. dts 5.1ch.
AVX Series For the ultimate in mobile entertainment, the AVX Series offers various configurations and features to select from. Each offers a brilliant combination of audio and visual technologies that demonstrate ECLIPSE’s commitment to enjoyable driving. AVX5000 DVD/MS Multi-Source Receiver with 7˝ Wide TFT Display 7˝ TFT display with touch control CD/CD-R/RW, WMA and MP3 DVD-Video, DVD-R/RW and DVD+R/RW Circle Surround Memory Stick Duo MOSFET 50W x 4 5.1 ch.
AVX2494 AVX2404 ’04 Product of the Year 6.5˝ Wide TFT Touch Panel VGA Display CD/DVD/MS Multi-Source Receiver with 20GB HDD for Music Juke Hi-Power CD/DVD/MS Receiver with 5.8˝ Touch-Panel TFT Display and MP3/5.1 Decoder Incorporating a 20GB HDD for immense music file storage as well as a brilliant VGA display, the AVX2494 offers the best of entertainment for audio and visual program material. An incredible performer, the AVX2404 is ready to offer any entertainment required.
A CD Receiver that changes all the rules. Along with a feature and function list that offers more than any other product in its class, the CD7000’s consummate performance and user customization features make it the audiophile choice.
CD7000 Special Features The CD7000 incorporates many new features and functions previously never seen in CD Receivers, redefining just what is possible to achieve on this platform. New CD Receivers GPS-linked volume control Combining style and function, the CD7000 incorporates stunning firsts such as the large, multi-color OEL display, GPS connectivity for enhanced driving assistance functions, and a rotary multi-function control that simplifies complex tasks.
E-iSERV This is where E-iSERV starts! www.eclipse-web.com E-iSERV advances Audio Customize ECLIPSE’s E-iSERV has raised user customization to a new level that many thought could not be done. By using the internet and a personal computer, the user can access functions and features that can optimize in-car system response and provide map guidance, along with customizing displays and enhanced control abilities.
NEW AREA SHOT The CD7000 and CD5000 make best use of enhanced GPS functions to assist driving when the optional GPS105 is connected. Automated map display switching Intersection-to-intersection displays GPS allows automated map switching, moving from one map display to the next as the car progresses along a route instead of having to manually shift from one map display to the next.
CD Receivers ECLIPSE’s latest CD Receivers incorporate technology and features that easily surpass conventional CD receivers by significantly improving basic audio performance, increasing user-customization options and refining map guidance functions. These are complete audio solutions for the mobile environment. Positioned at the top of the new CD Receiver lineup are the CD7000 and CD5000.
The CD4000 and CD3000 can easily be at the top of most CD Receiver lineups. Accommodating CDs, MP3 and WMA files, both these products offer superb audio performance as well as full user-customization features. CD4000 CD Multi-Source Receiver with Fully Motorized Face CD/CD-R/RW, WMA and MP3 E-iSERV connectivity Area Shot (arrow and text) 3 color LCD 5-pattern illumination SIRIUS Satellite Radio-ready Ready for iPod ® CD3000 MOSFET 50W × 4 (max.
CD Receivers The CD2000 and CD1000 represent the entry point to ECLIPSE products, but the performance of these products outshines labels. Maintaining ECLIPSE’s traditional emphasis on audio excellence by prioritizing features made it possible. CD2000 CD1000 MOSFET 50W × 4 (max.) CD Multi-Source Receiver CD/CD-R/RW, MP3 High contrast LCD SIRIUS Satellite Radio-ready • Bass/Mid/Treble control • 3-band GEQ • FM/AM tuner • 5V preamp output (front/rear/non-fader) • 3 prs.
Feature List CONTROL Remote Control CD Changer Control CD-R/CD-RW WMA MP3 ATRAC3 Decode (Memory Stick) Ready for iPod®* Sirius-ready HD Radio-ready Digital Servo System (DSS) TUNER FM / AM Station Name Input AUDIO Output Voltage and Impedance MOSFET Amplification Advanced 24-bit ∆∑ DAC Source Volume Control (SVC) Sound Control Mode CD7000 CD5000 CD4000 CD3000 CD2000 CD1000 ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● — ● ● ● ● Optional ● ● ● ● — ● ● ● ● Optional ● ● — ● — ▲ ● ● ● Optional —
Cassette Tuner Allowing those with extensive tape libraries to continue enjoying their favorite music with better performance than before, the 4502 is an ideal solution because it easily connects to an ECLIPSE CD Changer as well. 4502 • DSP EQ • Full logic Hybrideck tape mechanism • FM/AM tuner • Large 13-segment LCD • 5V preamp output with low 55Ω impedance • 3 prs.
Digital radio options Use this convenient option to connect to any of the compatible head units to take advantage of the digital broadcast content offered by a growing number of commercial radio stations. This option offers the easiest way to enjoy popular digital satellite broadcasting simply by connecting the SIR-ECL1 to a compatible head unit.
Power Amplifiers ECLIPSE power amplifiers feature advanced digital and analog circuit topologies to achieve maximum performance over a range of different power ratings.
ICEpower technology revitalizes the amplifier line. ® ECLIPSE’s latest power amplifiers feature new ICEpower ® technology. Seeing increasing use even in ultra high-end audiophile equipment, ICEpower ® advantages include superior audio quality, compactness and reduced energy demand as well as reliability. Employing ICEpower ® analog technology in ECLIPSE power amplifiers enable them to deliver stunning results in terms of linearity and reduced THD, increased dynamic range and high power stage efficiency.
Power Amplifier Series Joining the acclaimed EA Series is a brand new generation of power amplifiers, ECLIPSE’s XA Series which utilize analog ICEpower ® technology to create optimal amplification for the mobile environment. XA Amplifier Series ECLIPSE’s XA Amplifier Series utilize the latest advancements in digital amplification topologies to create superior sounding amplifiers dedicated for the mobile environment.
EA Amplifier Series The Integrated Amplifier Series offers outstanding sound quality with a distinctive appearance. Audiophile-grade power amplification is featured along with high current MOSFET switching power supplies that combine for dynamic performance with any speaker system. EA4000 • High current, high-efficiency MOSFET switching power supply delivers significant power when demanded. • Capable of high current delivery.
Subwoofers SW9100 Titanium Quad-Pro Series Pro Series SW9000 Series SW9182 Pro Continuing to rule as ECLIPSE’s top subwoofers, the SW9000 Series is also available in special competition-grade Pro configurations. Featuring Titanium Quad(4) and Double Voice Coil (DVC) technology to ensure quick response, high efficiency and extreme SPLs. The non-pro SW9000 Series offers Dual Voice Coils (DVC) with reference sound quality and ultra-low response that is taut and powerful with welldefined pitch.
SW8000 Series SW8200 SW8000 12˝ Subwoofer (4Ω) SW8000 Series 10˝ Subwoofer (4Ω) The heavy-duty SW8000 series is available in the most popular sizes and sports a distinctive look. • RMS power handling: 670W/625W • Max.
Subwoofers SW7000 Series SW7200 SW7000 12˝ Subwoofer (4Ω + 4Ω) SW7000 Series 10˝ Subwoofer (4Ω + 4Ω) The SW7000 Series incorporates a heatsink voice coil/cone thermal sink that allow producing 500W without strain. ECLIPSE’s low distortion/high excursion speaker cone design philosophy lets the speaker travel 1.4 inches, which is the most in its class. • RMS power handling: 500W/450W • Max.
SYSTEMS ECLIPSE subwoofer systems are constructed from sturdy wood, carefully assembled and well-damped for a tight bass. Finished in attractive and durable vinyl, these subwoofer systems are ready for final installation. Featuring a configuration specifically designed for the installation space requirements of trucks, SUVs and similar vehicles, the SW5124BX incorporates a special low-profile bass driver that saves space and still delivers a massive low frequency sound.
Component Series Speakers When size limitations are not a factor for speaker installations, ECLIPSE Component Series Speakers are an ideal choice. These are complete two- and three-way speaker systems with different components and crossovers designed to synergistically work together in perfect balance right from the start.
Point Source Series Speakers 2-Way SP-Series The SP Series II Point Source is an innovative 2-way component system that offers mounting options for the high frequency driver positioning flexibility in order to better meet installation requirements and achieve optimal sound. Woofers feature a new Kevlar composite for increased power handling and the external crossovers employ premium components.
Integrateed Series Speakers ECLIPSE Integrated Series speakers are integrated concentric units that are designed to replace factory speakers for significantly better music fidelity. Hybrid Mica PP Cone Woofer The ECLIPSE speaker cone is hybrid mica PP for rigidity under intense power, ensuring distortionfree performance. Butyl rubber surround The butyl rubber surround allows linear cone excursion and dampens cone resonance for undistorted dynamic peaks and clarity at all levels.
SE8465A 4 × 6˝ 2-Way SE8465E 4 × 6˝ 2-Way • RMS power handling: 30W • Max. power handling: 90W • RMS power handling: 30W • Max. power handling: 90W SE8365 6 × 1/2˝ 3-Way • RMS power handling: 40W • Max. power handling: 120W Marine Loudspeaker Specifically designed to withstand the rigors of marine and outdoors environments the SM6500 is ideal for use on boats. SE8245 4˝ 2-Way • RMS power handling: 25W • Max.
Notes and Precautions Product safety notice • To ensure the safe operation of ECLIPSE products, please read the owner’s manuals carefully prior to using. • ECLIPSE is not responsible for any accident or damage due to improper installation, connections or products modified in any way. Warning • All products are intended for DC 12-Volt operation in negative grounded vehicles only.
