Table Of Contents

How to use this manual
Features
- DVD player with sharp video and dynamic sound (Page 94)
- The MP3/WMA player that can play a disc holding many music tracks equivalent to several albums (Page 72)
- DSP effects for simulating acoustics of various performance environments (Page 30)
- Selection and display of favorite wallpaper (screen backgrounds) (Page 44)
- Radio tuner for receiving various broadcasts
- System additions
- TEL MUTE
- Easy-access audio controls on the steering wheel (Page 140)
Before using the main unit
- About discs
- About TV
- About the LCD panel
Switching mode
- Switching the mode
Operation screen of each mode
Adjusting the volume
- Adjusting main volume
Adjusting sound quality
- Setting DSP (acoustics)
- Adjusting EQ (equalizer)
- Setting POS (position selector)
- Adjusting volume balance
- Setting the BEEP tone
- Muting sound
- Switching the bass enhancement (Tru Bass)
- Setting LOUDNESS
- Setting the sub-woofer
- Setting the harmonizer
- Setting the Circle Surround II
Setting the background screen
- Setting the wallpaper
  - Changing the wallpaper
Adjusting the background screen
- Setting the opening screen
  - Changing the image on the opening screen
  - About usable image data
Adjusting/setting the screen
- Displaying the image adjustment screen
- Switching screen mode
How to use the AM / FM radio
- Listening to the AM/FM radio
- Selecting radio stations
- Selecting radio bands
- Saving radio stations
- Turning off the radio
How to use HD Radio
- Listening to HD Radio
- Selecting radio stations
- Saving radio stations
- Displaying information about the current broadcast
- Turning off the radio
How to use the SIRIUS satellite radio
- Listening to SIRIUS satellite radio
- Check the SIRIUS ID
- Changing the SIRIUS band
- Selecting the channel you want to listen to
  - Selecting from the available categories
  - Selecting a channel by direct input
- Displaying information about the current broadcast
- Turning off the SIRIUS
How to use the XM satellite radio
- Listening to XM satellite radio
- Check the XM ID
- Changing the XM band
- Selecting the channel you want to listen to
  - Selecting from the available categories
  - Selecting a channel by direct input
- Displaying information about the current broadcast
- Turning off the XM
How to use the CD player
- Listening to a CD
- Selecting a song
- Fast-forwarding/rewinding
- Searching for a song
- Repeating a song
- Playing songs in random order
- Turning off the CD player
How to use the MP3/WMA player
- Playing MP3/WMA
- Selecting a music file
  - Selecting with file change switches
  - Selecting with TUNE/TRACK button
- Fast-forwarding/rewinding
- Changing display of the current level
- Displaying the current level
- Searching for a music file
- Repeating the same music file
- Playing songs in random order
- About display of file information
  - Displaying folder/file names
  - Displaying file information
- Turning off the MP3/WMA player
- About MP3/WMA
- Making and playing MP3/WMA files
How to use the CD changer
- Listening to a CD
- Selecting a song
- Fast-forwarding/rewinding
- Selecting a CD
- Searching for a song or CD from all CDs in changer
  - Searching for a song
  - Searching for a CD
- Repeating a song or CD
  - Repeating the current song
  - Repeating the current CD
- Playing songs in random order
  - Playing songs on current CD in random order
  - Playing songs on all CDs in random order
- Turning off the CD player
Operating the iPod
- Listening to iPod
- Searching for a song in various ways
- Selecting a song
- Fast-forwarding/rewinding
Before using the DVD player
- DVD video characteristics
- About discs
- Products equipped with Macrovision
- About flow of operations
How to use the DVD player
- Watching a DVD
- Operating the video
- Operating the disc menu
- Turning off the DVD
- Searching for a desired chapter
- Changing the touch switch display
  - Turning off the touch switches
  - Changing the touch switch display locations
- Switching between screen display and audio
- Setting the DVD player
- Table of language codes
How to use the VTR
- Viewing the VTR
- Switching the VTR setting screen
- Turning off the VTR mode
How to use the TV
- Watching a TV
- Selecting channels
- Saving channels
- Switching the TV setting screen
- Turning off the TV mode
How to use the DUAL PLAY
- Setting the rear seat monitor
- Operating the rear seat monitor
- How to play CD
- How to play MP3/WMA
- How to play DVD
- How to watch TV
  - Selecting a channel
    - Selecting a channel manually
About the steering wheel switches
- Function names and summaries
How to use an optional remote control (RMC105)
- Turning the power on/off
- Adjusting the audio volume
  - Muting the Volume
- Switching playback modes
- How to play the tuner
  - Selecting a station (manually or automatically)
  - Selecting preset stations
- How to play CDs
- Replacing the battery
Information you should know
- If one of these messages appears
- Before asking for repairs
Glossary
Index by topic
- About screen and sound adjustment
- About Using AM/FM radio
- Usage when an HD Radio tuner is connected
- Usage when a SIRIUS satellite radio tuner is connected
- Usage when a XM satellite radio tuner is connected
- About using the CD player/CD changer
- About using the MP3/WMA player
- About using the iPod
- About using the DVD player
- About using the VTR
- About using the TV tuner
- Useful functions
- When something isn't clear
INDEX

How to operate the DVD player

DVD

How to use the DVD player

A DVD can be watched only if the vehicle is completely stopped in a safe location with the

parking brake set and the ignition switch turned to ON or ACC. (Only sound can be heard if

a DVD is played while the car is in motion.)

Watching a DVD

Start playback by inserting a DVD into the DVD insertion slot, which will automatically turn on

power.

Press while a disc is inserted.

Touch .

Touch .

• Playback will begin.

• If the operation switches (touch switches) are not being displayed, press or

touch the screen.

Button

Buttons off switch

Angle change

switch

Subtitles change

switch

Title number Chapter number Playing time

Chapter changing/

Fast-forward (rewind) Button

Audio change

switch

Button

SOURCE MENU

switch

SOURCE

DVD
