TILLER/CULTIVATOR OPERATOR'S MANUAL Tiller/Cultivator Operator's Manual MODEL TC-210 Serial Number 05001001 - 05999999 WARNING DANGER Read rules for safe operation and instructions carefully. ECHO provides an Operator's Manual, which must be read and understood for proper and safe operation.
INTRODUCTION Welcome to the ECHO family. This ECHO product was designed and manufactured to provide long life and on-the-job-dependability. Read and understand this manual. You will find it easy to use and full of helpful operating tips and SAFETY messages. THE OPERATOR'S MANUAL Read and understand this manual before operation. Keep it in a safe place for future reference.
TILLER/CULTIVATOR OPERATOR'S MANUAL SAFETY SYMBOLS AND IMPORTANT INFORMATION Throughout this manual and on the product itself, you will find safety alerts and helpful, information messages preceded by symbols or key words. The following is an explanation of those symbols and key words and what they mean to you. This symbol accompanied by the words WARNING and DANGER calls attention to an act or condition that can lead to serious personal injury to operator and bystanders.
INTERNATIONAL SYMBOLS Symbol form/shape Symbol form/shape Symbol description/application Symbol form/shape Read and understand Operator's Manual. Symbol description/application Symbol form/shape Avoid all power lines. This unit is not insulated against electrical current. Symbol description/application Fuel and oil mixture Symbol description/application Emergency stop Ignition ON/OFF Engine choke control. Wear eye, hea and hearing protection Finger Severing Hot Surface Wear hand protection.
TILLER/CULTIVATOR OPERATOR'S MANUAL EXTENDED OPERATION/EXTREME CONDITIONS Vibration and Cold -It is believed that a condition called Raynaud’s Phenomenon, which affects the fingers of certain individuals may be brought about by exposure to vibration and cold. Exposure to vibration and cold may cause tingling and burning sensations followed by loss of color and numbness in the fingers. The following precautions are strongly recommended because the minimum exposure which might trigger the ailment is unknown.
SAFE OPERATION WARNING DANGER Do not operate this product indoors or in inadequately ventilated areas. Engine exhaust contains poisonous emissions and can cause serious injury or death. TO AVOID INJURY : • • • • • • • • • • • • • Read and understand the OPERATOR’S MANUAL. Know location and functions of all controls. Keep all Safety devices and shields in place. Never allow children or uninstructed adults to operate the unit Shut off engine before unclogging tines or making repairs.
TILLER/CULTIVATOR OPERATOR'S MANUAL DESCRIPTION The ECHO product you purchased has been factory pre-assembled for your convenience. Due to packaging restrictions some assembly is required. After opening the carton, check for damage. Immediately notify your retailer or ECHO Dealer of damaged or missing parts. Use the contents list to check for missing parts.
1. STOP SWITCH - Toggle Switch mounted on upper right handle. Move switch forward to "Start" position to run, back to "Stop" position to stop unit. 2. THROTTLE TRIGGER - Spring loaded to return to idle when released. When accelerating, pull trigger gradually for best operating technique. DO NOT hold trigger when starting. 3. SAFETY DECAL - General safety precautions - See Page 3. 4. SPARK PLUG - Provides spark to ignite fuel mixture. 5.
TILLER/CULTIVATOR OPERATOR'S MANUAL SPECIFICATIONS MODEL ----------------------------------------------------- TC-210 Length ------------------------------------------------------- 1130 mm (44.48 in.) Width -------------------------------------------------------- 340 mm (13.36 in.) Height ------------------------------------------------------- 1010 mm (39.76 in.) Weight (dry) w/Tines ------------------------------------- 8.62 kg (19 lb.
ASSEMBLY Tools Required: (2) 7/16 in. Wrenches 1. Support powerhead assembly upright on tines. Place top handle assembly to rear. NOTE Make sure inside curves at handle ends are facing each other. A C,D 2. Loosely assemble lower handles using short 1/4 in. x 3 in. long hex head shoulder bolt (A), eye plates (B), lockwasher (C), and locknut (D) in front handle end mounting hole as shown. 3.
TILLER/CULTIVATOR OPERATOR'S MANUAL 11 PRE-OPERATION FUEL Fuel Requirements Gasoline - Use 89 Octane [R+M/2] (mid grade or higher) gasoline known to be good quality. Gasoline may contain up to 15% MTBE (methyl tertiary-butyl ether). Gasohol containing methyl (wood) alcohol is NOT approved. Two Stroke Oil - A two-stroke engine oil meeting ISO-L-EGD (ISO/CD 13738) and J.A.S.O. FC Standards, must be used. Echo brand Premium 50:1 oil meets these standards.
OPERATION STARTING COLD ENGINE WARNING DANGER The tines should not move at idle. If tines move, readjust carburetor according to "Carburetor Adjustment" instructions in this manual or see your ECHO Dealer, otherwise serious personal injury may result. A 1. Stop Switch Move Stop Switch (A) to "START" position. 2. Choke Move choke (B) to "COLD START" position. Throttle must remain at idle position for starting. 3.
TILLER/CULTIVATOR OPERATOR'S MANUAL STARTING WARM ENGINE The starting procedure is the same as cold start except DO NOT close the choke (B). NOTE If engine does not start after 5 pulls, use Cold Start Procedure. A 1. Stop Switch Move Stop Switch (A) to START position. Throttle trigger must remain at idle position for starting. 2. Primer Pump primer bulb (C) until fuel is visible and flows freely in the clear fuel tank return line. Pump bulb an additional 4 or 5 times. 3.
TILLING/CULTIVATING WARNING DANGER Do not operate this unit indoors or in inadequately ventilated areas. • Carry unit to tilling/cultivating area using plastic carry handle and upper handle. Avoid contact with tines or hot engine parts. • Check the area to be tilled or cultivated. Look for any hazards and obstructions that could contribute to unsafe conditions. • Remove all rocks, debris, and other materials that could become jammed in the tines.
TILLER/CULTIVATOR OPERATOR'S MANUAL 15 MAINTENANCE Your ECHO tiller/cultivator is designed to provide many hours of trouble free service. Regular scheduled maintenance will help your tiller/cultivator achieve that goal. If you are unsure or are not equipped with the necessary tools, you may want to take your unit to an ECHO Service Dealer for maintenance. To help you decide whether you want to DO-IT-YOURSELF or have the ECHO Dealer do it, each maintenance task has been graded.
AIR FILTER Level 1. Tools required: 25-50mm (1-2 in.) medium bristle paint brush. Parts required: 90008 REPOWERTM AIR & FUEL FILTER KIT. 1. Close choke (Cold Start Position). This prevents dirt from entering the carburetor throat when the air filter is removed. Brush accumulated dirt from the air cleaner area. 2. Remove the air cleaner cover. Clean and inspect the element for damage. If element is fuel soaked and very dirty, replace. 3.
TILLER/CULTIVATOR OPERATOR'S MANUAL SPARK PLUG Level 2. Tools Required: Spark Plug socket wrench and screw driver, Feeler gauge. Preferably a wire gauge. Parts Required: Spark Plug, NGK - BPM-8Y P/N 15901019830 1. Remove spark plug and check for fouling, worn and rounded center electrode. 2. Clean the plug or replace with a new one. DO NOT sand blast to clean. Remaining sand will damage engine. 3. Adjust spark plug gap by bending outer electrode. 4. Tighten spark plug to 145-155 kg/cm (125-135 in. lb.).
3. Remove bottom left (A) and bottom right (B) screws from cylinder cover. 4. Carefully pull cylinder cover forward, disengaging muffler gasket tabs and ignition lead, and lay aside. 5. Use brush to remove dirt from cylinder fins. IMPORTANT DO NOT use a metal scraper to remove dirt from the cylinder fins. B A 6. Assemble components in reverse order.
TILLER/CULTIVATOR OPERATOR'S MANUAL CARBURETOR ADJUSTMENT Level 2. Tools required: Screwdriver, Tachometer (ECHO P/N 99051130017). Parts required: None. NOTE Every unit is run at the factory and the carburetor is set in compliance with emission regulations. In addition, the carburetor is equipped with HI (A) and LO (B) needle adjustment limiters that prevent settings outside acceptable limits. 1. Before adjusting the carburetor, clean or replace the air filter and spark arrestor screen.
LUBRICATION Level 1. Tools Required: Crosshead Screw Driver, Clean Rag Parts Required: ECHO® LUBETM 8 oz. (P/N 91015) or Lithium Base Grease. Gear Housing 1. Remove tines (See Tine Removal/Cleaning - Installation below). D 2. Clean dirt from area around gear cover (A) and remove four (4) crosshead screws (B). Be careful not to tear sealing gasket (C). 3. Support tiller with exposed gear case (D) upward. Add grease until nearly level with top of gear case (D). IMPORTANT Do not over fill.
TILLER/CULTIVATOR OPERATOR'S MANUAL 21 TROUBLESHOOTING EN GIN E PR OB LEM TR OU B LESH OOTIN G C H AR T Problem C h eck Status Fuel at carburetor No fuel at carburetor No fuel at cyli nder Engi ne cranks starts hard/ doesn't start Engi ne runs, but di es or does not accelerate properly C au se R emedy Fuel strai ner clogged Fuel li ne clogged C arburetor C lean or replace C lean or replace See your Echo dealer C arburetor See your Echo dealer Fuel at cyli nder Muffler wet wi th fuel Fuel Mi x
STORAGE Long Term Storage (over 30 days) WARNING DANGER During operation the muffler or catalytic muffler and surrounding cover become hot. Always keep exhaust area clear of flammable debris during transportation or when storing, otherwise serious property damage or personal injury may result. Do not store your unit for a prolonged period of time (30 days or longer) without performing protective storage maintenance which includes the following: 1.
TILLER/CULTIVATOR OPERATOR'S MANUAL NOTES 23
SERVICING INFORMATION PARTS Genuine ECHO Parts and ECHO REPOWER™ Parts and Assemblies for your ECHO products are available only from an Authorized ECHO Dealer. When you do need to buy parts always have the Model Number and Serial Number of the unit with you. You can find these numbers on the engine housing. For future reference, write them in the space provided below. Model No. _____________ SN. ____________ DEALER? Call 1-800-432-ECHO or www.echo-usa.
