ECHO 1 User's Manual For AGES 18 and up -Warning This AEG is FOR AGES 18 and above. This AIR SOFT gun can cause serious injury if misused. Full face protection is required. Please read through the MANUAL BEFORE USE to avoid damages and injuries.
ECHO 1 User Manual It is your RESPONSIBILITY to know your local and state laws regarding the OWNERSHIP, USE and TRANSPORT of your air soft gun. If you are unsure of the laws, contact your local law enforcement agency or state government. «Wear full eye and face protection at all times when handling or using an air soft gun. « Always keep your air soft gun pointed in a safe direction. »Always keep your softball gun unloaded until ready to use.
| STAG 15 Rifle Front Sight Flash Hider Front Sight 2 'STAG M4 Carbine Flash Hider Magazine Catch Magazine Specs of the Gun nine T Solid Stock Magazine Catch Magazine Trigger Removable Carry Handle Rear Sight Selector Switch Motor Grip Removable Carry Handle Rear Sight Adjustable LE Stock Selector Switch Motor Grip Name of Gun STAG M4 Carbine Weight 6.3lb Barrel Length 363mm Overall Length 760mm Barrel Caliber 6.08mm Ammo Capacity 300 BB's BB Size 6mm Feet Per Second 360-370fps Battery Type 8.
ECHO 1 User Manual Battery Installation Charge the battery for 3 hours for the first time. When charging have the battery away from ALL COMBUSTIBLE MATERIALS and on cool hard surface. If battery becomes HOT remove from charger and let it COOL before use. When cycle rate becomes slow, STOP shooting and remove magazine. Shoot 2 times in SEMI to clear the gun, remove battery and recharge. Models: STAG M4 RIS, Echo 1 614, MOD 4 CQB, COMBAT To install the battery in the battery box follow these step.
ECHO 1 User Manual How to use the Magazine Avoid getting dirt and Tips for operation: debris into the magazine Use caution when mag seems empty. this can cause it to malfunction. There are 30 ebb's left in the loading tube. Wind/Turn the gear approximately 7-10 times, every 30-50 ebb's fired. 1. Press the magazine release 2. Open the top hatch and 3. Close the hatch. 4. Hold the mag with the BB top to remove the magazine. pour ebb's. About 300 ebb's hatch facing up and turn the can be loaded, do not gear.
ECHO 1 User Manual Adjusting the Hop Up Hop Up Adjustment Wheel When adjusting the hop up make sure your shooting area is clear Bolt cover and safe to shoot. If the hop up is too high it may jam and damage the gun. Charging Handle: Pull back gently /Pulling the charging handle opens the dust cover. Once opened it must be closed manually Eflfii%iii? \ Make sure dirt and debris does not get into the g . hop up.
