i.LON SmartServer 2.0 Programmer’s Reference
7-7
Property Description
<UCPTuri>
The name of the file containing the configuration web page
for the Alarm Notifier on the SmartServer flash disk,
absolute or relative to /web/user/echelon folder. This
property is
#8000010128000000[4].UFPTalarmNotifier_Cfg.htm
by default.
<SCPTdelayTime>
The minimum time (in seconds) that must pass after this
Alarm Notifier has logged an alarm notification before the
e-mail profiles for the Alarm Notifier can be used, or the
output data points for this Alarm Notifier can be updated.
This property defaults to 0.
<UCPTsumLogSize>
The size of the summary alarm log file, in kilobytes. The
summary alarm log includes records for all current
acknowledged and unacknowledged alarms.
Please note that the total size of the log files for all Alarm
Notifiers (and Data Loggers) on the SmartServer can not
exceed the size of the flash memory stored in the
SmartServer. The SmartServer will stop writing to the log
files when it only has 256 Kb of flash memory remaining.
<UCPThistLogSize>
The size of the historical alarm log file, in kilobytes. The
historical alarm log contains a record for any acknowledged
alarm. Each record includes the description,
acknowledgment time and comment entered for the alarm.
Please note that the total size of the log files for all Alarm
Notifiers (and Data Loggers) on the SmartServer can not
exceed the size of the flash memory stored in the
SmartServer. The SmartServer will stop writing to the log
files when it only has 256 Kb of flash memory remaining.
<UCPTlogFormat>
Either LF_BINARY or LF_TEXT. This property
determines whether the log file will be generated as a binary
file, or as a text file.
<UCPTemailAggregTime>
The time, in milliseconds, to wait after an alarm occurs
before using the email profiles defined for the Alarm
Notifier. This may be useful if you want to prevent multiple
e-mails from being sent to the same address at the same
time.
The default value used if you do not define this property is
0. The maximum value is 65,535 milliseconds.
Note: The <UCPTemailAggregTime> counter resets every
time an alarm occurs. Therefore, if multiple alarms occur
before the aggregation period expires, the emails for those
alarms will be merged and sent as a single email
notification. The SmartServer will send the email
automatically after 100 alarms have been merged. This may
be useful if multiple alarms occur within a few moments of
each other, but you should take it into consideration before
setting this property to a high value.
