i.LON SmartServer 2.0 Programmer’s Reference
6-4
<UCPTlastUpdate>2008-02-28T15:45:26.060-08:00</UCPTlastUpdate>
<UCPTuri>#8000010128000000[4].UFPTalarmGenerator_Cfg.htm</UCPTuri>
<DataPoint dpType="nviEnable" discrim="dir_in" >
<UCPTname>Net/LON/iLON App/Alarm Generator[0]/nviAgEnable[0]</UCPTname>
</DataPoint>
<DataPoint dpType="nvoAlarmFlag" discrim="dir_out" >
<UCPTname>Net/LON/iLON App/Alarm Generator[0]/nvoAgAlarmFlag[0]</UCPTname>
</DataPoint>
<DataPoint dpType="nviLatchEnable" discrim="dir_in" >
<UCPTname>Net/LON/iLON App/Alarm Generator[0]/nviAgLatchEnbl[0]</UCPTname>
</DataPoint>
<DataPoint dpType="Input" discrim="dir_in" >
<UCPTname>Net/LON/iLON App/Digital Output 1/nviClaValue_1</UCPTname>
</DataPoint>
<DataPoint dpType="Compare" discrim="dir_in" >
<UCPTname>Net/LON/iLON App/Alarm Generator[0]/CompareDP</UCPTname>
</DataPoint>
<DataPoint dpType="Alarm" discrim="dir_out" >
<UCPTname>Net/LON/iLON App/Alarm Generator[0]/alarm</UCPTname>
</DataPoint>
<UCPTalrmIhbD>0.000000</UCPTalrmIhbD>
<UCPTalarmPriority LonFormat="UCPTalarmPriority">PR_LEVEL_1</UCPTalarmPriority>
<UCPTpollOnResetDelay>0.0</UCPTpollOnResetDelay>
<UCPTpollRate>0.0</UCPTpollRate>
<UCPTalarm2Description></UCPTalarm2Description>
<UCPTcompFunction LonFormat="UCPTcompFunction">FN_EQ</UCPTcompFunction>
<UCPTalarmSetTimeD>0.000000</UCPTalarmSetTimeD>
<UCPTalarmClrTimeD>0.000000</UCPTalarmClrTimeD>
<UCPTlowLimit1Offset LonFormat="UNVT_double_float"></UCPTlowLimit1Offset>
<UCPTlowLimit2Offset LonFormat="UNVT_double_float"></UCPTlowLimit2Offset>
<UCPThighLimit1Offset LonFormat="UNVT_double_float"></UCPThighLimit1Offset>
<UCPThighLimit2Offset LonFormat="UNVT_double_float"></UCPThighLimit2Offset>
<SCPThystHigh1 LonFormat="UNVT_double_float"></SCPThystHigh1>
<SCPThystHigh2 LonFormat="UNVT_double_float"></SCPThystHigh2>
<SCPThystLow1 LonFormat="UNVT_double_float"></SCPThystLow1>
<SCPThystLow2 LonFormat="UNVT_double_float"></SCPThystLow2>
</Item>
</iLonItem>
</GetResponse>
The function returns an <Item> element for each Alarm Generator referenced in the input parameters
supplied to the function. The properties included in each element are initially defined when the Alarm
Generator is created. You can write to these properties with the Set function. The following table
describes these properties.
Property Description
<UCPTname>
The name of the Alarm Generator in the following format:
<network/channel/device/functional block>.
<UCPTannotation>
The program ID and functional profile template used by the
Alarm Generator. This property is always
8000010128000000[4].UFPTalarmGenerator
<UCPThidden>
A flag indicating whether the Alarm Generator functional
block is hidden or shown in the navigation pane on the left
side of the SmartServer Web interface. This property may
have the following values:
0 – shown
1 – hidden
<UCPTitemStatus>
This property only appears if the data logger is not
synchronized with an LNS network database or it has been
