i.LON SmartServer 2.0 Programmer’s Reference
4-22
Property Description
<UCPTname>
The name of the source data point in the Web connection in
following format: <network/channel/device/functional
block/data point>.
<UCPTannotation>
The direction of the data point in the Web connection. This is
always Dp_In_WebBinding.
<UCPThidden>
A flag indicating whether the source data point in the Web
connection is hidden or shown in the navigation pane on the left
side of the SmartServer Web interface. This property may have
the following values:
0 – shown
1 – hidden
<UCPTlastUpdate>
A timestamp indicating the last time the configuration of the
data point was updated. This timestamp uses the ISO 8601
format, which is as follows:
YYYY-MM-DDTHH:MM:SS.sssZPhh:mm
The first segment of the time stamp (YYYY-MM-DD)
represents the date the configuration of the Data Point was last
updated. The second segment (after the T): HH:MM:SS.sss
represents the time of day the configuration of the Data Point
was last updated, in UTC (Coordinated Universal Time).
UTC is the current term for what was commonly referred to as
Greenwich Meridian Time (GMT). Zero (0) hours UTC is
midnight in Greenwich England, which lies on the zero
longitudinal meridian. Universal time is based on a 24-hour
clock; therefore, an afternoon hour such as 4 pm UTC would be
expressed as 16:00 UTC. The Z appended to the timestamp
indicates that it is in UTC. It can be left out.
For example, 2002-08-15T10:13:13Z indicates a UTC time of
10:13:13 AM on August 15, 2002. If it is not UTC, time shift
has to be defined: 2008-02-28T09:59:53.660+01:00
<UCPTdescription>
A user-defined description of the Web connection. This can be
a maximum of 201 characters long. By default, this property is
“Generated by WB web UI”
<UCPTuri>
The name of the file containing the Web connection data on the
SmartServer flash disk. This property is always Dp_Ref.htm.
<DataPoint>
Target
The target data point in the Web connection. This data point is
updated every time a Write function is performed on the source
data point in the Web connection. This data point has the
following properties:
• <UCPTname>. The name of the target data point in the
Web connection in following format:
<network/channel/device/functional block/data point>.
• <UCPTserviceType>. Web connections always use
