i.LON SmartServer 2.0 Programmer’s Reference

4-13

Response

<UCPTname>Net/LON/iLON App/VirtFb/temp_thermostat</UCPTname>

<UCPTvalue LonFormat="UCPTvalueDef">OCCUPIED</UCPTvalue>

</Item>

<UCPTname>Net/LON/iLON App/VirtFb/nviSwitch</UCPTname>

</Item>

<UCPTname>Net/LON/iLON App/VirtFb/nvoSetting</UCPTname>

<UCPTvalue LonFormat="#0000000000000000[0].SNVT_setting" Unit="function, setting, rotation"

>SET_OFF 0.0 0.00</UCPTvalue>

<UCPTvalue LonFormat="#0000000000000000[0].SNVT_setting.function" Unit="setting control

function names">SET_OFF</UCPTvalue>

<UCPTvalue LonFormat="#0000000000000000[0].SNVT_setting.setting" Unit="% of full level"

>0.0</UCPTvalue>

<UCPTvalue LonFormat="#0000000000000000[0].SNVT_setting.rotation" Unit="degrees"

>0.00</UCPTvalue>

</Item>

</iLonItem>

</ReadResponse>

The following table describes the properties of each <Item> element returned by the Read function.

Property Description

The name of the data point in the following format:

<network/channel/device/functional block/data point>.

The direction of the data point (Dp_In, Dp_Out, or Dp_In_Out

[unspecified]), and its xsi type, which corresponds to the bus on

which the data point resides (e.g., LON_Dp_Cfg for a L

ONWORKS

data point) . This determines the icon used to represent the data

point in the navigation pane on the left side of the SmartServer

Web interface.
