i.LON SmartServer 2.0 Programmer’s Reference
19-12
Property Description R/W
<UCPTmailLogin> The user name for logging in to an SMTP server that
requires authentication. The SmartServer and the SMTP
server will automatically negotiate the authentication
mechanism to be used (PLAIN, LOGIN, or
CRAM-MD5). The SmartServer does not support the
POP before SMTP authentication mechanism.
r/w
`<UCPTmailPassword> The password used for logging in to an SMTP server
that requires authentication.
r/w
19.1.7
IP-852 Router Settings
You can use the SystemService_Read_Info function to get the settings of the SmartServer’s internal
IP-852 router. To do this, you provide the SystemService_Read_Info function with an
<iLONSystemService> element that includes one <UCPTsystemInfoType> property that is set to
SI_RTR.
Request
<SystemService_Read_Info xmlns="http://wsdl.echelon.com/web_services_ns/ilon100/v4.0/message/">
<iLONSystemService>
<UCPTsystemInfoType>SI_RTR</UCPTsystemInfoType>
</iLONSystemService>
</SystemService_Read_Info>
Response
<SystemService_Read_Info xmlns="http://wsdl.echelon.com/web_services_ns/ilon100/v4.0/message/">
<iLONSystemService>
<RTR>
<UCPTrouterType>Configured</UCPTrouterType>
<UCPTrouterAuthKey>00:00:00:00:00:00:00:00:00:00:00:00:00:00:00:00</UCPTrouterAuthKey>
<UCPTip852ConfigServerAddr>10.2.124.77</UCPTip852ConfigServerAddr>
<UCPTip852ConfigServerPort>1629</UCPTip852ConfigServerPort>
<UCPTip852LocalPort>1628</UCPTip852LocalPort>
<UCPTrouterL
ONWORKSAddr_IP>B3/2/1</UCPTrouterLONWORKSAddr_IP>
<UCPTrouterL
ONWORKSAddr_LT>B3/1/2</UCPTrouterLONWORKSAddr_LT>
</RTR>
</iLONSystemService>
<SystemService_Read_Info xmlns="http://wsdl.echelon.com/web_services_ns/ilon100/v4.0/message/">
The SystemService_Read_Info function returns one <RTR> item. The following table lists and
describes the properties of the <RTR> item. You can use the SystemService_Write_Info function to
configure those properties that are marked (r/w).
Property Description R/W
<UCPTrouterType>
• This property specifies the router type. You can use
the SystemService_Write_Info function to change
the IP-852 router to a Repeater. You cannot change
the IP-852 router to any other router type.
• Configured. The router determines which packets
to forward based on internal routing tables. These
routing tables contain one entry for each subnet in
the application domain. Whenever a router receives
a packet, it examines the source and destination
subnet ID to determine whether to forward the
packet. This is the recommended type because it
optimizes network traffic and enables the channels
r
