i.LON SmartServer 2.0 Programmer’s Reference

19-9

Property Description R/W

used to accommodate block failures.

The recommended minimum number of spare flash

blocks (8 blocks). If a flash block on the SmartServer

fails and there are no spare blocks remaining, the flash

disk may become unreliable. The SmartServer should

be replaced before this happens.

The maximum rate of erases/minute of the

SmartServer flash disk.

This property specifies whether a SmartServer

Programming Activation Key is installed on the

SmartServer. This property may be one of the

following values:

• PS_REGISTERED

• PS_ UNREGISTERED

A SmartServer Programming Activation Key must be

installed on a SmartServer in order to deploy freely

programmable modules (FPMs) on it. For more

information on creating and deploying FPMs, see the

i.LON SmartServer Programming Tools User’s Guide.

19.1.5

Real-Time System Information

You can use the SystemService_Read_Info function to get general network performance statistics for

the SmartServer, including the current flash memory usage, CPU utilization, data point message

failures, and the time of last Web browser refresh. To do this, you provide the

SystemService_Read_Info function with an <iLONSystemService> element that includes one

<UCPTsystemInfoType> property that is set to SI_REAL_TIME.

Request

<SystemService_Read_Info xmlns="http://wsdl.echelon.com/web_services_ns/ilon100/v4.0/message/">

</iLONSystemService>

</SystemService_Read_Info>

Response

<SystemService_Read_Info xmlns="http://wsdl.echelon.com/web_services_ns/ilon100/v4.0/message/">

<REAL_TIME>
