i.LON SmartServer 2.0 Programmer’s Reference
19-1
19 System Information Methods
You can use the SystemService_Read_Info and SystemService_Write_Info functions in the
iLON100_System.wsdl to read system information about the SmartServer and modify the
SmartServer’s configuration. You can use the SystemService_Test function to test connections to
various host devices such as SMTP mail servers, SNTP time servers, and remote SmartServers and
read the results of the tests.
Note: To use the system information methods, you must reference the iLON100_System.wsdl in your
code. See
Chapter 20, Using the SOAP Interface as a Web Service, for more information on adding
service references.
19.1
System Service Methods
You can use the SystemService_Read_Info and SystemService_Write_Info functions to read system
information about the SmartServer and modify the SmartServer’s configuration.
The SystemService_Read_Info and SystemService_Write_Info functions take a string consisting of an
<iLONSystemService> element that includes one <UCPTsystemInfoType> property. The
<UCPTsystemInfoType> property specifies an enumeration representing the type of system
information to be read from and written to the SmartServer. The following example demonstrates how
to use the SystemService_Read_Info function in your code:
string systemData = "<iLONSystemService><UCPTsystemInfoType>SI_TIME
</UCPTsystemInfoType></iLONSystemService>"
Tip: Section 21.1.7, Configuring the SmartServer in Visual C# .NET, includes a C# programming
example demonstrating how to use the SystemService_Read_Info and SystemService_Write_Info
functions.
Section 21.2.7, Configuring the SmartServer in Visual Basic.NET, includes a Visual Basic
example demonstrating how to do this.
The following table lists the values to which you can set <UCPTsystemInfoType> and the type of
system information returned by the SystemService_Read_Info function:
<UCPTsystemInfoType> Data Returned by SystemService_Read_Info
SI_NETWORK SmartServer IP connections, including IPv4, IPv6, and
DNS server connections.
SI_TIME SmartServer real-time clock settings.
SI_SECURITY SmartServer security settings.
SI_STATIC
(read-only)
General information about the SmartServer, including
the following:
• Hardware and firmware versions.
• Flash memory capacity and limits.
• FPM license status.
SI_REAL_TIME
(read-only)
General network performance statistics for the
SmartServer, including the following:
• Current flash memory usage.
• CPU utilization.
• Data point message failures.
